Schurter IEC Appliance Inlet C14 Connector with 2-Pole Line Switch, 250V AC 2A, Screw Mount, Quick Connect 3-103-777

Free Delivery in India | Lowest Global Shipping Charges

Schurter IEC Appliance Inlet C14 Connector with 2-Pole Line Switch, 250V AC 2A, Screw Mount, Quick Connect 3-103-777

Name: Schurter IEC Appliance Inlet C14 Connector with 2-Pole Line Switch, 250V AC 2A, Screw Mount, Quick Connect 3-103-777
Brand: Schurter
SKU: 426330
Price: 20.22 USD
Availability: InStock



Category IEC Connector Brand Schurter Condition New

Specifications

Country of Origin	Slovakia
Voltage	250V ac
Brand	Schurter
Current	2A
Height	31.5mm
Filter Type	Line
Depth	65.9mm
Mount Type	Screw
Operating Frequency	50, 60Hz
Switch Type	2 Pole
Series	DD14
Termination Type	Quick Connect
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-25°C
Panel Mount	Snap-in or screw-on mounting from front side
Fuse Size	5 x 20 mm
IEC Connector Type	C14
4 Functions	Appliance Inlet Protection class I, Line Switch 2-pole, Fuseholder for fuse-links 5 x 20 mm 1 or 2 pole, 2-Stages line filter in standard and medical version

Key Features

Rated for 250V AC voltage and 2A current for reliable operation.
Equipped with a 2-pole line switch and fuseholder compatible with 5 x 20 mm fuse size.
Quick connect terminals measuring 6.3 x 0.8 mm for fast wiring.
Screw mounting with snap-in or screw-on panel options from front side.
Compact dimensions of 31.5 mm height and 65.9 mm depth.
Ultra-compact aluminium housing provides excellent shielding and durability.
V-Lock cord retaining ensures secure cable connection and safety.
Operating temperature range from -25°C to 85°C.

Product Description

Schurter 3-103-777 is a high-quality IEC Appliance Inlet C14 connector designed for industrial and electronic applications requiring reliable power entry solutions. This connector integrates a 2-pole line switch, fuseholder for standard 5 x 20 mm fuse-links (1 or 2 pole), and a 2-stages line filter, providing multiple functions including appliance inlet protection class I and line filtering suitable for standard and medical environments.

The device is ultra-compact with an aluminium case that offers superior shielding against electromagnetic interference, ensuring stable performance in high transient load applications. Mounting is versatile with screw or snap-in options from the front side of panels, complemented by a V-Lock cord retaining notch to secure cables during operation.

Its quick connect termination type (6.3 x 0.8 mm terminals) allows for fast and reliable electrical connections. The unit is rated for 250V AC and 2A current, supporting operating frequencies of 50 to 60 Hz. Operating temperature specifications range from -25°C to 85°C, making it suitable for a wide range of industrial and commercial environments.

This power entry module is an ideal choice for use in various sectors including electronics manufacturing, medical devices, laboratory equipment, industrial machinery, and HVAC systems where compact size and comprehensive functionality are essential.

Rated for 250V AC and 2A current providing reliable power handling. Incorporates a 2-pole line switch and fuse holder for 5 x 20 mm fuses. Quick connect terminals for efficient wiring and maintenance. Flexible mounting options with front snap-in or screw panel mount.

Aluminium casing ensures excellent electromagnetic shielding. V-Lock cord retention system secures cable connections effectively. Wide operating temperature range suitable for diverse environments. 2-stage line filtering for enhanced electrical noise suppression.
