Schurter Non-Resettable Fuse 1A 125V DC 250V AC Ceramic Body Time Delay UMZ 250 Series 3404.2416.22

Free Delivery in India | Lowest Global Shipping Charges

Schurter Non-Resettable Fuse 1A 125V DC 250V AC Ceramic Body Time Delay UMZ 250 Series 3404.2416.22

Name: Schurter Non-Resettable Fuse 1A 125V DC 250V AC Ceramic Body Time Delay UMZ 250 Series 3404.2416.22
Brand: Schurter
SKU: 425482
Price: 1.36 USD
Availability: InStock



Category Non-Resettable Fuse Brand Schurter Condition New

Specifications

Country of Origin	Switzerland
Voltage	125, 250V dc
Brand	Schurter
Body Material	Ceramic
Height	3.9mm
Depth	10.1mm
Width	3.8mm
Current Rating	1A
Series	UMZ 250
Maximum Operating Temperature	-40°C
Package Type	Reel
Minimum Operating Temperature	85°C
Breaking Capacity	200A
Terminal Material	Gold Plated Copper
Standards/Approvals	CE, CSA, RoHS, UL 248-14, REACH
Fuse Characteristics	Time Delay

Key Features

Designed for high breaking capacity applications up to 200A.
Surface mount fuse with gold plated copper terminals.
Operates reliably between -40°C and 85°C ambient temperatures.
Certified to international standards including CE, CSA, RoHS, UL 248-14, and REACH.
Ideal for protecting sensitive electronic components such as ICs, audio/visual equipment, and medical devices.
Time-lag fuse characteristic provides delay to avoid nuisance blowing during transient surges.
Supplied on reel packaging for efficient production use.

Product Description

Schurter 3404.2416.22 non-resettable fuse is a high-quality protective device with a 1 amp current rating designed to operate at voltages of 125V DC and 250V AC. Featuring a robust ceramic body, this fuse incorporates time delay characteristics suitable for applications requiring short-term surge tolerance.

With compact dimensions of 3.8mm width, 3.9mm height, and 10.1mm depth, it is engineered for surface-mount technology, offering space-saving advantages in circuit design. The gold plated copper terminals ensure reliable electrical connectivity and resistance to corrosion, enhancing product longevity.

This fuse provides a high breaking capacity of 200 amps, making it suitable for industrial, laboratory, and commercial electronics environments. It is widely used for protection in alarm systems, audio and video equipment, computer boards, portable telephones, power supplies, and medical apparatus.

Operating temperature ratings from -40°C to 85°C allow this fuse to perform reliably under varied environmental conditions. The product complies with international safety and environmental standards including CE, CSA, RoHS, UL 248-14, and REACH, ensuring adherence to industry regulations.

Packaged on reels, the fuse is ready for automated insertion, improving assembly efficiency in manufacturing processes. The UMZ 250 series fuse represents Schurter’s commitment to durability and performance in fuse protection solutions.

High breaking capacity up to 200A for robust circuit protection. Time delay fuse characteristic to handle transient surges. Ceramic body with gold plated copper terminals for durability and connectivity. Compact surface mount design for space-saving applications.

Operating temperature range from -40°C to 85°C for varied conditions. Compliance with CE, CSA, RoHS, UL 248-14, and REACH standards. Ideal for electronic device protection in industrial, medical, and commercial use cases.

Supplied in reel packaging to optimize manufacturing assembly. Explore more circuit protection solutions under the Non-Resettable Fuse category at EnvMart to find products tailored for your industrial and electrical needs.
