Schurter Non-Resettable Fuse Ceramic Body 160mA 250V AC 125V DC Time Delay UMZ 250 Series 3404.2408.22

Free Delivery in India | Lowest Global Shipping Charges

Schurter Non-Resettable Fuse Ceramic Body 160mA 250V AC 125V DC Time Delay UMZ 250 Series 3404.2408.22

Name: Schurter Non-Resettable Fuse Ceramic Body 160mA 250V AC 125V DC Time Delay UMZ 250 Series 3404.2408.22
Brand: Schurter
SKU: 425483
Price: 1.46 USD
Availability: InStock



Category Non-Resettable Fuse Brand Schurter Condition New

Specifications

Country of Origin	Switzerland
Voltage	250, 125V ac
Brand	Schurter
Body Material	Ceramic
Height	3.9mm
Depth	10.1mm
Width	3.8mm
Current Rating	160mA
Series	UMZ 250
Maximum Operating Temperature	-40°C
Package Type	Reel
Minimum Operating Temperature	85°C
Breaking Capacity	200A
Terminal Material	Gold Plated Copper
Standards/Approvals	CSA, UL 248-14, RoHS, REACH, CE
Fuse Characteristics	Time Delay

Key Features

Current rating of 160mA suitable for low power electronic circuits.
Ceramic body material ensures high durability and thermal resistance.
Time delay fuse characteristics protect sensitive electronic components from transient surges.
Surface mount device with gold-plated copper terminals for reliable connectivity.
Breaking capacity of 200 amps enhances circuit safety during fault conditions.
Operating temperature range from -40°C to 85°C supports varied environmental conditions.
Packaged in a reel format suitable for automated assembly processes.

Product Description

Schurter 3404.2408.22 Non-Resettable Fuse features a ceramic body and time delay characteristic designed for reliable overcurrent protection in electronic circuits. It is rated for 160mA current with a maximum AC voltage of 250 volts and DC voltage of 125 volts.

This fuse is part of the UMZ 250 series and is intended for surface mount technology applications, offering significant space-saving on printed circuit boards. Its gold-plated copper terminal material provides excellent conductivity and corrosion resistance.

The compact dimensions (3.8mm width, 3.9mm height, and 10.1mm depth) make it ideal for high-density circuit designs. The fuse supports a breaking capacity of 200 amps, ensuring robust fault clearance capability.

Operating temperature is rated between -40°C and 85°C, allowing use in varied industrial, industrial automation, telecommunications, and electronic manufacturing applications. The fuse complies with standards IEC 60127-4 / 2, UL 248-14, CSA C22.2 no. 248.14, RoHS, REACH, and CE, confirming its quality and safety credentials.

Current rating of 160mA supports low power electronic protection. High voltage rating up to 250V AC and 125V DC. Ceramic body construction for enhanced thermal and mechanical durability. Time delay fuse characteristic protects against transient surges.

Gold-plated copper terminals ensure reliable solderability and electrical contact. Compact surface mount package suited for automated manufacturing. Breaking capacity of 200A ensures robust circuit protection. Wide operating temperature range from -40°C to 85°C.

Complies with IEC, UL, CSA, RoHS, REACH, and CE standards.

This non-resettable fuse is suitable for use in industrial equipment, telecommunication devices, medical apparatus, consumer electronics, power supplies, and other applications requiring reliable overcurrent protection. Its surface mount design supports high volume automated assembly lines improving manufacturing efficiency.
