HARTING SEK 18 Series Straight Through Hole Shrouded PCB Header, 50 Contacts, 2.54 mm Pitch, 2 Row, 1A Current 09185506927

Free Delivery in India | Lowest Global Shipping Charges

HARTING SEK 18 Series Straight Through Hole Shrouded PCB Header, 50 Contacts, 2.54 mm Pitch, 2 Row, 1A Current 09185506927

Name: HARTING SEK 18 Series Straight Through Hole Shrouded PCB Header, 50 Contacts, 2.54 mm Pitch, 2 Row, 1A Current 09185506927
Brand: HARTING
SKU: 213173
Price: 22.2 USD
Availability: InStock



Category PCB Headers Brand HARTING Condition New

Specifications

Country of Origin	Switzerland
Voltage	1kV
Brand	HARTING
Orientation	Straight
Current	1A
Mount Type	Through Hole
Housing Material	Polybutylene Terephthalate
Contact Material	Copper Alloy
Series	SEK 18
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	50
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board

Key Features

The header features 2 rows of contacts ensuring compact and reliable connection.
Constructed with polybutylene terephthalate housing for durability.
Contacts are made from copper alloy with gold plating for excellent conductivity and corrosion resistance.
Designed for a current rating of 1 ampere and voltage up to 1 kV.
Operating temperature range from -55°C to 125°C enables use in diverse environments.
Termination by soldering and includes male contact gender with wrap post type connectors.
Compliant with IEC 60 603-13 standards ensuring quality and reliability.

Product Description

HARTING 09185506927 SEK 18 Series is a shrouded, straight through hole PCB header designed for reliable wire-to-board connections. This component features 50 male contacts arranged in 2 rows with a standard 2.54 mm pitch, suitable for high-density PCB applications.

Constructed with a durable polybutylene terephthalate housing, the header ensures mechanical stability and resistance to environmental stresses. The contact pins are made of copper alloy and gold plated to provide superior conductivity and corrosion resistance, enhancing long-term electrical performance.

Rated for 1 ampere current and capable of withstanding voltages up to 1 kilovolt, it supports a wide operating temperature range from -55°C to 125°C. This makes it suitable for industrial, electronic, and manufacturing applications that require thermal endurance and consistent electrical contact.

The termination type is solder, with wrap post connectors providing a robust mechanical connection to the PCB. The standard is IEC 60 603-13, ensuring compliance with internationally recognized specifications. Note that headers are supplied without ejectors; compatible locking levers and ejectors are available separately (stock numbers 693-5163 and 693-5176).

The header includes 50 contacts arranged in two rows with 2.54 mm pitch. Housing made of polybutylene terephthalate for durability and insulation. Contact material is copper alloy with gold plating for corrosion resistance and conductivity.

Rated for 1A current and 1kV voltage operation. Operating temperature ranges between -55°C and 125°C. Designed for through hole mounting and solder termination. Male contact gender with wrap post style connectors. Manufactured in Switzerland meeting IEC 60 603-13 standards.

This PCB header is ideal for applications in electronic component manufacturing, industrial controls, automation systems, and instrumentation requiring high-reliability connectors. Its robust construction and electrical properties ensure prolonged performance in demanding environments.
