Bourns 1210 Shielded Wirewound Surface Mount Inductor with Ferrite Core 1 μH ±10% 230 mA Idc Q:30 CM322522
Specifications
| Country of Origin | India |
|---|---|
| Brand | Bourns |
| Height | 2.2mm |
| Length | 3.2mm |
| Model | CM322522 |
| Depth | 2.5mm |
| Packaging | Tape & Reel |
| Series | CM322522 |
| Maximum Operating Temperature | 100°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 1μH |
| Standards/Approvals | RoHS |
| Package/Case | 1210 |
| Maximum DC Current | 230mA |
| Pin Count | 2 |
| Maximum DC Resistance | 690mΩ |
| Inductance Tolerance | ±10 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 115MHz |
| Minimum Quality Factor | 30 |
| Inductor Construction | Wirewound |
Key Features
- Features a ferrite core for enhanced magnetic properties.
- Package size is 1210 with compact 3.2mm length and 2.5mm depth.
- Offers a minimum quality factor (Q) of 30 ensuring efficient performance.
- Shielded design reduces electromagnetic interference and enhances circuit reliability.
- Suitable for AV equipment, wireless communications, and general electronic applications.
- Operates reliably across -40°C to 100°C temperature range.
- Moulded wirewound construction ensures durability and stable operation.
- Termination style is solder for surface mount compatibility.
Product Description
Bourns CM322522 is a 1210 shielded wirewound surface mount inductor featuring a ferrite core and a nominal inductance of 1 μH with ±10% tolerance. It can handle a maximum DC current of 230 mA and has a quality factor of at least 30, making it suitable for precise and reliable inductive applications.
This inductor has a compact form factor with dimensions of 3.2 mm in length, 2.2 mm height, and 2.5 mm depth, optimized for space-constrained surface mount circuit designs. Its shielded ferrite core construction minimizes electromagnetic interference, enhancing circuit stability and performance in high-frequency environments up to 115 MHz.
The product is moulded and uses a solder termination style, providing secure and reliable mounting on PCBs. It operates effectively in a broad temperature range from -40°C to 100°C, making it adaptable to harsh industrial and commercial environments.
This wirewound inductor is commonly used in AV equipment, wireless communications, power supplies, and general electronic equipment requiring precision inductors with stable performance.
Ferrite core for improved magnetic properties and reduced losses. Shielded design for electromagnetic interference suppression. Compact 1210 package suitable for high-density PCB layouts. RoHS compliant, supporting environmentally safe manufacturing processes.
Moulded wirewound construction ensures durability. High-quality factor for efficient signal filtering and power management.
The Bourns CM322522 enhances electronic designs with reliable inductive performance conforming to rigorous industry standards. For advanced surface mount Inductors, explore related products in the electronics components category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Bourns CM322522 inductor has a nominal inductance of 1 μH with a tolerance of ±10%.
This model can handle a maximum DC current of 230 mA.
The dimensions of the CM322522 are 3.2 mm in length, 2.2 mm in height, and 2.5 mm in depth.
It offers a minimum quality factor (Q) of 30, ensuring efficient performance in applications.
This inductor operates reliably across a temperature range of -40°C to 100°C.
The CM322522 features a ferrite core, which enhances its magnetic properties and reduces losses.
The termination style for this model is solder, making it compatible with surface mount applications.
The maximum self-resonant frequency of the Bourns CM322522 is 115 MHz.
This inductor is packaged in tape and reel format for convenient handling and assembly.
The product is RoHS compliant, supporting environmentally safe manufacturing processes.
It is suitable for use in AV equipment, wireless communications, power supplies, and general electronic applications.
This inductor features a moulded wirewound construction, ensuring stable operation.
