STMicroelectronics Linear Voltage Regulator 35V SOT-89 3-Pin L78L15ACUTR
Specifications
| Country of Origin | India |
|---|---|
| Voltage | Regulators STMicroelectronics, Voltage Regulator 35V SOT-89 3-Pin RS Stock No |
| Brand | STMicroelectronics |
| Height | 1.6mm |
| Length | 4.6mm |
| Model | L78L15ACUTR |
| Width | 2.6mm |
| Mount Type | Surface |
| Series | L78Lxx |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-89 |
| Polarity | Positive |
| Maximum Input Voltage | 35V |
| Quiescent Current | 6.5mA |
| Pin Count | 3 |
Key Features
- Provides a stable positive output voltage with low quiescent current of 6.5mA.
- Designed to deliver up to 100mA output current with an internal current limiting feature.
- Encapsulated in compact SOT-89 package measuring 4.6mm length, 2.6mm width, and 1.6mm height.
- Features thermal shutdown protection to prevent overheating above 150°C maximum operating temperature.
- Suitable for surface mount applications requiring efficient voltage regulation.
- Non-automotive grade with no specific automotive standards compliance.
- Ideal for use in power management circuits, embedded systems, and electronic component designs.
Product Description
STMicroelectronics L78L15ACUTR linear voltage regulator is a 3-pin, positive polarity device housed in a compact SOT-89 surface mount package. Designed for power management IC applications, it supports a maximum input voltage of 35V and operates reliably up to 150°C.
With an internal current limiting feature and thermal shutdown protection, the L78L15ACUTR provides up to 100mA of regulated output current with a low quiescent current of 6.5mA, making it efficient for embedded electronic systems.
The device dimensions are 4.6mm in length, 2.6mm in width, and 1.6mm in height, supporting surface mount PCB assembly for compact electronic designs. This voltage regulator is suitable for various industrial, electronic component, embedded system, and power management use cases that require reliable and steady voltage supply.
Provides a stable positive output voltage with low quiescent current of 6.5mA. Designed to deliver up to 100mA output current with an internal current limiting feature. Encapsulated in compact SOT-89 package measuring 4.6mm length, 2.6mm width, and 1.6mm height.
Features thermal shutdown protection to prevent overheating above 150°C maximum operating temperature. Suitable for surface mount applications requiring efficient voltage regulation. Non-automotive grade with no specific automotive standards compliance.
Ideal for use in power management circuits, embedded systems, and electronic component designs. Explore additional Voltage Regulators and power management ICs on EnvMart for your electronic design and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum input voltage for this model is 35V.
It is designed to deliver up to 100mA of output current.
The quiescent current for this voltage regulator is 6.5mA.
The dimensions of the SOT-89 package are 4.6mm in length, 2.6mm in width, and 1.6mm in height.
The maximum operating temperature is 150°C.
Yes, it features thermal shutdown protection to prevent overheating.
This voltage regulator is suitable for power management circuits, embedded systems, and electronic component designs.
This model has a pin count of 3.
The L78L15ACUTR has a positive polarity.
Yes, it is encapsulated in a compact SOT-89 package, making it suitable for surface mount applications.
It belongs to the L78Lxx series of voltage regulators.
The country of origin for this model is India.
