HARWIN M20 Series Right Angle Through Hole PCB Socket 16-Contact 2 Row 2.54 mm Pitch M20-7880846

The HARWIN M20-7880846 is a right angle, through hole PCB socket designed for robust board-to-board applications requiring high reliability and compact configuration. This 16-contact, 2-row socket features a 2.54 mm pitch and is manufactured with a high-temperature nylon housing certified UL94V-0, making it capable of withstanding harsh electronic assembly processes, including reflow soldering.

Its bronze contacts are coated with tin over nickel plating and designed as durable dual beam contacts for excellent electrical engagement and connector reliability over time. The socket supports currents up to 12A per contact and operates across temperatures from -40°C to 105°C, facilitating use in diverse industrial, consumer, and commercial electronic equipment.

The M20 series connectors are well-suited for embedded PCs, consumer electronics, industrial monitoring, communications equipment, drives, and controllers where board-to-board connectivity is essential. The right angle orientation enables optimal PCB layout to meet density and height constraints.

With a typical mating lifecycle of up to 300 operations, these sockets ensure prolonged service life, reducing maintenance needs and improving overall system reliability. Compact design tailored for dense PCB arrangements and height limitations.

Housing material provides high-temperature resistance as per UL94V-0 standards. Highly reliable dual beam bronze contacts plated with tin over nickel enhance conductivity and durability. Supports through hole mounting with solder termination ensuring mechanical robustness.

Electrical current rated at 12A per contact suitable for demanding electronic applications. Operating temperature range from -40°C to 105°C allows use in varied environments. Manufactured to meet standard PCB socket configurations with 16 contacts arranged in 2 rows.

Applications include industrial monitoring, embedded computing, consumer electronics, and communications equipment.

This product is manufactured in China and provides an industry-standard solution for PCB connectivity challenges. EnvMart offers these connectors as part of a comprehensive range of PCB Sockets and connectors for electronics manufacturing and development.
