HARWIN M22 Series Straight Through Hole PCB Socket 6-Contact 2 Row 2 mm Pitch 500V 12A M22-7140342
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 500V |
| Brand | HARWIN |
| Orientation | Straight |
| Current | 12A |
| Model | M22-7140342 |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Bronze |
| Series | M22 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | Socket Strip |
| Minimum Operating Temperature | -25°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 6 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Compact design with 2 mm pitch suitable for high-density PCB applications.
- Constructed with liquid crystal polymer housings rated UL94V-0 for high temperature resistance.
- High-reliability gold plated dual beam contacts ensure reliable electrical connection.
- Supports up to 300 mating operations for durable performance.
- Suitable for board-to-board connections with through-hole mounting type and straight orientation.
- Operating temperature range from -25°C to 105°C.
- Contact material is bronze with gold plating for corrosion resistance.
- Current rating of 12A per contact at 500V voltage rating.
Product Description
HARWIN M22-7140342 Straight Through Hole PCB Socket is a 6-contact, 2-row socket connector with a fine 2 mm pitch designed for board-to-board applications. This PCB socket features a compact and robust design suitable for increased PCB density and height restrictions in electronics assemblies.
The connector housing is made of UL94V-0 high-temperature liquid crystal polymer, providing excellent resistance to reflow soldering processes. It employs highly durable gold plated dual beam contacts that enhance electrical connectivity and improve reliability across numerous mating cycles, supporting up to 300 mating operations.
This M22 series PCB socket is rated for 12 A current per contact and 500 V voltage, making it suitable for demanding electronic circuits. It supports through-hole mounting with a straight orientation for optimal connection to PCBs, ensuring mechanical and electrical stability.
The socket’s bronze contacts with gold plating offer corrosion resistance, and the operating temperature range of -25°C to 105°C ensures reliability in harsh industrial and commercial environments. These sockets are commonly used in high-performance motherboards, embedded systems, industrial monitoring, consumer electronics, communications, drives, and controls.
Compact 2 mm pitch design supports increased PCB density. High-temperature liquid crystal polymer housings resist reflow soldering. Gold plated dual beam contacts offer reliable and durable electrical connections. Supports 12 A current rating and 500 V voltage per contact.
Designed for through-hole mounting with straight orientation. Operating temperature range from -25°C to 105°C allows wide environmental application. Suitable for embedded PCs, industrial controls, communications, and consumer electronics.
Supports up to 300 mating cycles for long service life. Contact material: bronze with gold plating for corrosion resistance. Available in single and double row, various contact configurations.
These HARWIN M22 Series PCB Sockets are standard connectors in electronics manufacturing, enabling compact, high-density board-to-board connectivity. Explore similar PCB connectors and sockets in our catalog for your industrial and commercial projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The HARWIN M22-7140342 PCB socket has a current rating of 12A per contact and a voltage rating of 500V.
This model features a compact design with a pitch size of 2 mm, suitable for high-density PCB applications.
The housing is made from liquid crystal polymer, and the contacts are bronze with gold plating for corrosion resistance.
The operating temperature range for the HARWIN M22-7140342 is from -25°C to 105°C.
This socket has a total of 6 contacts arranged in 2 rows.
It supports through-hole mounting with a straight orientation, ensuring optimal connection to PCBs.
This model supports up to 300 mating operations, enhancing its durability for repeated use.
Yes, the HARWIN M22-7140342 is designed for board-to-board connections, making it suitable for various electronic applications.
The termination type for this model is solder, which is commonly used for secure connections in PCB assemblies.
This socket is commonly used in high-performance motherboards, embedded systems, industrial monitoring, consumer electronics, and communications.
The contact gender of the HARWIN M22-7140342 is female, designed for connecting with male contacts.
The HARWIN M22-7140342 is manufactured in Taiwan.
