HARWIN M22-63 Series Straight Surface PCB Socket, 24-Contact, 2 Row, 2 mm Pitch, Solder Termination, 250V, 12A M22-6361242

HARWIN M22-6361242 is a high-quality PCB socket from the M22-63 series, featuring a straight surface mount design with 24 female contacts arranged in 2 rows at a 2 mm pitch. Designed for board-to-board applications, this connector provides robust and reliable electrical connections with a compact footprint suitable for high-density PCB layouts.

The socket housing is manufactured using UL94V-0 rated Nylon, which offers excellent heat resistance to withstand typical reflow soldering processes. The bronze contacts plated with gold provide superior conductivity and corrosion resistance, improving connector longevity and performance. With a current rating of 12A per contact and voltage rating of 250V, it supports demanding electronic environments.

This product is designed to endure up to 105°C operating temperature and withstands up to 300 mating cycles due to the durable dual beam contact design. These features ensure long-term reliability in industrial, commercial, and personal computing applications such as embedded PCs, motherboards, drives, and control systems.

The M22-63 series sockets meet industry standards for board-level connectors and are widely used in consumer electronics, communications equipment, and industrial monitoring devices. Its solder termination and surface mount style simplify assembly and enhance manufacturing efficiency.

Set contains a single PCB socket with 24 contacts in a 2-row configuration, suitable for compact and high-density electronics designs. Compact straight surface mount design for PCB applications. High temperature-resistant Nylon housing provides durability.

Gold-plated bronze female contacts ensure reliable electrical performance. Rated for 12A current and 250V voltage. Supports operating temperatures up to 105°C. Dual beam contact design offers up to 300 mating cycles. Ideal for embedded PCs, motherboards, industrial monitoring, and communications.

Available in single and double row configurations. Constructed for commercial and industrial electronics use. Browse the Electronics & Electricals category on EnvMart for more connectors and PCB socket solutions.
