Amphenol Communications Solutions Minitek Series Right Angle Through Hole PCB Header, 6 Contacts, 2 mm Pitch 98464-G61-06LF
Specifications
| Country of Origin | France |
|---|---|
| Voltage | 200V |
| Brand | Amphenol Communications Solutions |
| Orientation | Right Angle |
| Current | 2A |
| Model | 98464-G61-06LF |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | Minitek |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 2.5mm |
| Mating Pin Length | 4mm |
Key Features
- The connector supports a current rating of 2 A, suitable for low power PCB applications.
- It includes a shrouded header design to protect the contacts and ensure reliable mating.
- The housing is made of durable thermoplastic material providing good insulation.
- Gold-plated copper alloy contacts ensure low resistance and corrosion resistance.
- The orientation is right angle to facilitate board-to-board connectivity.
- This component is designed for through hole mounting with solder termination type.
- Operating temperature range is from -40°C to 125°C, suitable for harsh environments.
- Mating pin length is 4 mm with a tail pin length of 2.5 mm for reliable solder connections.
Product Description
Amphenol Communications Solutions 98464-G61-06LF Minitek Series PCB Header is a right angle, double row, through hole connector designed for board-to-board applications. It features 6 male contacts with 2 mm pitch, enabling compact and reliable circuitry connections.
The housing is constructed from high-quality thermoplastic material, ensuring good electrical insulation and mechanical protection. The contacts are made from copper alloy with gold plating, providing excellent conductivity and corrosion resistance, critical for industrial and electronic applications.
This shrouded header offers tactile guidance and prevents mismating, enhancing connection reliability in assembly. Its right angle orientation is ideal for designs requiring perpendicular PCB interfaces.
The connector supports a current of 2 A and withstands voltages up to 200 V, making it suitable for various electronics, industrial controls, and communication devices. Its operating temperature range from -40°C to 125°C allows use in demanding environments.
Solder termination and through hole mounting techniques facilitate robust mechanical and electrical solder joints on printed circuit boards. The connector supports a current rating of 2 A, suitable for low power PCB applications.
It includes a shrouded header design to protect the contacts and ensure reliable mating. The housing is made of durable thermoplastic material providing good insulation. Gold-plated copper alloy contacts ensure low resistance and corrosion resistance.
The orientation is right angle to facilitate board-to-board connectivity. This component is designed for through hole mounting with solder termination type. Operating temperature range is from -40°C to 125°C, suitable for harsh environments.
Mating pin length is 4 mm with a tail pin length of 2.5 mm for reliable solder connections. Voltage rating is 200 V, meeting typical PCB requirements.
The 98464-G61-06LF model is manufactured in France to stringent quality standards, making it a reliable choice for electronic component engineers, prototyping, and production assembly lines.
Explore more connectors and PCB accessories in the Electronics Components category at EnvMart for your project needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 2 A, making it suitable for low power PCB applications.
The voltage rating for this connector is 200 V, which meets typical PCB requirements.
It operates within a temperature range of -40°C to 125°C, suitable for harsh environments.
This connector features 6 male contacts arranged in a double row configuration.
The pitch size of the contacts is 2 mm, allowing for compact circuitry connections.
The housing is made from thermoplastic material, while the contacts are made from gold-plated copper alloy for low resistance and corrosion resistance.
This model is designed for through hole mounting with solder termination type.
The orientation of this connector is right angle, facilitating board-to-board connectivity.
The mating pin length is 4 mm, while the tail pin length is 2.5 mm for reliable solder connections.
This connector is manufactured in France to stringent quality standards.
It is designed as a board-to-board connector system, enhancing connectivity between PCBs.
The shrouded header design protects the contacts and ensures reliable mating, preventing mismating during assembly.
