TE Connectivity Eurocard 48 Way 2.54 mm Pitch DIN 41612 Through Hole 3 Row Male Connector 8-1393644-0
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V ac |
| Brand | TE Connectivity |
| Orientation | Right Angle |
| Current | 1.5A |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | Eurocard |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | C/2 |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 3 |
| Pitch | 2.54mm |
| Standards/Approvals | RoHS |
| Number of Contacts | 48 |
| Contact Gender | Male |
| Connector Gender | Male |
| Maximum Contact Resistance | 15mΩ |
| Row Loading | A/B/C |
Key Features
- Meets DIN 41612 and IEC 60603-2 standards for high signal integrity.
- Contains 48 contacts arranged in 3 rows with a pitch of 2.54 mm.
- Rated for 250V AC voltage and 1.5A current capacity.
- Made with flame retardant thermoplastic housing material.
- Features solder termination and through hole mounting type.
- Operates reliably between -55°C to 125°C temperature range.
- Includes polarization features to prevent mis-mating.
- Contacts constructed of copper alloy with maximum resistance of 15 milliohms.
Product Description
TE Connectivity 8-1393644-0 Eurocard 48 Way DIN 41612 Connector provides a high-quality electrical connection solution designed for industrial, telecommunications, and data system applications. This connector features 48 contacts arranged in 3 rows with a 2.54 mm pitch, constructed to meet the DIN 41612 and IEC 60603-2 standards ensuring excellent signal integrity and reliability.
The connector is a male type, right angle orientation with solder termination and through hole mounting style designed for PCB assembly. Its flame retardant thermoplastic housing enhances durability and safety, and the copper alloy contacts offer low contact resistance up to 15 milliohms. Operating temperature ranges from -55°C to 125°C make it suitable for diverse environmental conditions.
It incorporates polarization and locking features to ensure secure mating and prevent connection issues. This Eurocard connector is widely used in modular rack systems, backplane assemblies, data centers, industrial control systems, and telecommunications equipment.
Complies with DIN 41612 and IEC 60603-2 standards. 48 contacts, 3 row configuration with 2.54 mm pitch. Solder class C2 with through hole mounting. Maximum 1.5A current capacity and 250V AC voltage rating. Thermoplastic housing material with flame retardant properties.
Wide operating temperature range from -55°C to 125°C. Copper alloy contact material for reliable conduction. Used extensively in high-speed trains, data centers, and modular electronic systems.
Choose TE Connectivity for proven performance in demanding electronic connector applications. Explore related DIN 41612 Connectors and compatible accessories at EnvMart for comprehensive electronic component solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a voltage rating of 250V AC.
The current capacity is rated at 1.5A.
This connector features 48 contacts arranged in 3 rows.
The contacts are arranged with a pitch of 2.54 mm.
It uses through hole mounting for PCB assembly.
The housing is made of flame retardant thermoplastic, and the contacts are constructed from copper alloy.
It operates reliably between -55°C to 125°C.
It features solder termination.
Yes, it complies with DIN 41612 and IEC 60603-2 standards.
The maximum contact resistance is 15 milliohms.
This connector has a right angle orientation.
It is widely used in modular rack systems, backplane assemblies, data centers, and telecommunications equipment.
