HARWIN M80 Series Straight Surface PCB Socket, 50-Contact, 2 Row, 2 mm Pitch, 120V, 12A, Solder Termination M80-4125042
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Voltage | 120V |
| Brand | HARWIN |
| Orientation | Straight |
| Current | 12A |
| Model | M80-4125042 |
| Mount Type | Surface |
| Housing Material | Polyphenylene Sulphide |
| Contact Material | Beryllium Copper Alloy |
| Series | M80 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Datamate |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 50 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Equipped with 50 high-quality female contacts arranged in 2 rows for stable connectivity.
- Utilizes solder termination type for secure attachment to PCBs.
- Made with durable Polyphenylene Sulphide housing and gold-plated Beryllium Copper alloy contacts.
- Rated for operating voltages up to 120V and current capacity of 12A.
- Designed to function reliably in temperatures ranging from -55°C to 125°C.
- Features a straight orientation suitable for board-to-board connector systems.
- Ideal for applications requiring vibration resistance and frequent mating cycles.
- Manufactured to meet high industrial standards without approvals listed.
Product Description
HARWIN M80-4125042 PCB Socket is a straight surface mount connector designed for high performance electronic applications requiring robustness and reliability. With 50 female contacts arranged in two rows at a 2 mm pitch, it supports board-to-board connections with a current rating of 12A and voltage up to 120V. This socket features solder termination ensuring dependable mechanical and electrical contact.
The housing is constructed from Polyphenylene Sulphide (PPS), which provides excellent durability and chemical resistance. Contacts are fabricated from Beryllium Copper alloy with gold plating, ensuring excellent conductivity and corrosion resistance. Operating temperature ranges from -55°C to 125°C, making it suitable for harsh industrial environments.
The M80 series connectors are specifically engineered to withstand high vibration, shock, and acceleration, making them ideal for critical applications in industrial, automotive, and aerospace sectors. The straight orientation and robust contact design ensure secure engagement and reliable signal transmission over extended usage cycles.
Additionally, these sockets comply with BS9525-F0033, MIL C 55302, and CEC 75101-008 standards, ensuring compatibility with COTS applications and established industry criteria. Equipped with 50 female contacts arranged in 2 rows for reliable connections.
Solder termination type ensures strong mechanical and electrical integrity. Housing made from durable Polyphenylene Sulphide material. Beryllium Copper alloy contacts plated with gold for optimal conductivity. Supports operating temperatures from -55°C to 125°C.
Rated for up to 120V voltage and 12A current capacity. Designed for board-to-board connector systems with straight orientation. Ideal for harsh environment applications with vibration and shock resistance. Manufactured in the United Kingdom.
This HARWIN M80-4125042 surface PCB Socket is an excellent choice for electronic components requiring reliable, high-quality board connectors. Explore more industrial and electronic components on EnvMart for your professional needs.
