ASSMANN WSW A-BL254 Series Straight Through Hole PCB Socket, 20-Contact, 2 Row, 2.54 mm Pitch Solder A-BL254

ASSMANN WSW A-BL254 Series Straight Through Hole PCB Socket A-BL254 is engineered for precision PCB mounting and connectivity. This double row female header socket features 20 contacts with 2.54 mm pitch and 3.20 mm pin length, making it ideal for dense PCB layouts in industrial electronics and manufacturing environments.

The socket’s bronze contact material with gold plating ensures superior electrical conductivity and corrosion resistance, enhancing signal integrity and long component life. The housing is made of black PBT certified to UL 94 V-0 flame retardant standard, providing mechanical durability and safety compliance.

Designed with a through hole solder termination type and straight orientation, it integrates smoothly into printed circuit boards, supporting a maximum operating voltage of 500 V and continuous current of 12 A. It operates reliably in ambient temperatures ranging from -40°C to 105°C, maintaining performance across diverse conditions found in industrial, laboratory, and manufacturing settings.

This PCB socket complies with UL standards and originates from China. It caters to applications including electronic assembly, PCB prototyping, repair, and other relevant industrial and commercial uses where robust PCB connectivity is required.

The female PCB socket features a 2.54 mm pitch and 3.20 mm pin length for secure connections. Double row configuration improves contact density and board space utilization. Constructed with bronze contacts and gold plating to ensure excellent conductivity and corrosion resistance.

Black PBT housing rated UL 94 V-0 offers strong flame retardance and mechanical stability. Termination via through hole solder mounting supports durable PCB integration. Rated for 12 A current and 500 V voltage to support various electronic circuits reliably.

Operates within a wide temperature range from -40°C to 105°C for harsh environments. Meets UL 94 V-0 safety standards for electrical components. Suitable for industrial, electronics manufacturing, repair, and prototyping applications.
