ASSMANN WSW 64-Way IDC Connector Female for Cable with 2 Row 250V AC 1A AWP 64-7240-T
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 250V ac |
| Brand | ASSMANN WSW |
| Orientation | Right Angle |
| Current | 1A |
| Model | AWP 64-7240-T |
| Mount Type | Cable |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Brass |
| Series | AWP |
| Termination Type | IDC |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold over Nickel |
| Number of Contacts | 64 |
| Contact Gender | Female |
| Connector Gender | Female |
| Shrouded/Unshrouded | Shrouded |
Key Features
- Features 64 contacts in a double row configuration for efficient cable connections.
- Shrouded female connector designed with gold over nickel plating for durability and corrosion resistance.
- Has a pitch of 2.54mm and a right angle orientation for versatile PCB applications.
- Constructed with brass contacts and a polybutylene terephthalate housing meeting UL94V-0 standards.
- Operates reliably in temperatures from -55°C to 105°C ensuring broad environmental tolerance.
- Utilizes insulation displacement contact (IDC) termination for secure and fast cable connections.
- Suitable for industrial, electronics manufacturing, and automated assembly use cases.
Product Description
The ASSMANN WSW AWP 64-7240-T is a high-quality 64-way IDC connector female designed for cable mounting, featuring a dual-row arrangement suitable for ribbon cable connections in a range of electronics applications.
This connector operates at a voltage rating of 250V AC and a current rating of 1 ampere, making it ideal for low-power industrial or electronic assembly environments. The shrouded design and gold-over-nickel contact plating enhance connector reliability and lifespan in harsh conditions.
Its 2.54mm pitch and right angle orientation provide flexible integration into PCB designs, while the brass contact material and polybutylene terephthalate housing ensure robust mechanical and electrical performance. The housing complies with UL94V-0 flame retardant standards to enhance safety.
Engineered to tolerate temperatures ranging from -55°C to 105°C, this connector accommodates a diverse range of operating environments from cold storage to industrial processes. The IDC termination type facilitates rapid, dependable connections without soldering, simplifying assembly and maintenance.
Applications span from industrial machinery wiring, electronic component assemblies, to complex automated control systems. The product is manufactured in China and supplied new, maintaining consistent quality.
Features 64 contacts in a double row configuration for efficient cable connections. Shrouded female connector designed with gold over nickel plating for durability and corrosion resistance. Has a pitch of 2.54mm and a right angle orientation for versatile PCB applications.
Constructed with brass contacts and a polybutylene terephthalate housing meeting UL94V-0 standards. Operates reliably in temperatures from -55°C to 105°C ensuring broad environmental tolerance. Utilizes insulation displacement contact (IDC) termination for secure and fast cable connections.
Suitable for industrial, electronics manufacturing, and automated assembly use cases. Explore more IDC Connectors and electronic components from ASSMANN WSW on EnvMart for diverse industrial and commercial requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector has a voltage rating of 250V AC and a current rating of 1 ampere.
It features a pitch of 2.54mm and a right angle orientation, making it suitable for versatile PCB applications.
This model has 64 contacts arranged in a double row configuration.
The connector is constructed with brass contacts and a polybutylene terephthalate housing.
It operates reliably in temperatures ranging from -55°C to 105°C.
This connector utilizes insulation displacement contact (IDC) termination for secure and fast cable connections.
Yes, it is suitable for industrial, electronics manufacturing, and automated assembly use cases.
The connector features a 2.54mm pitch and is designed for cable mounting, but specific dimensions are not provided.
The contacts are plated with gold over nickel to enhance durability and corrosion resistance.
The housing complies with UL94V-0 flame retardant standards, enhancing safety.
The connector is manufactured in China.
This connector is a female connector, designed for cable mounting.
