ASSMANN WSW 9-Way 2 Row Shrouded IDC Connector Female for Cable, 250V AC, 1A Current A-DFF 09LPIII/Z-UNC
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 250V ac |
| Brand | ASSMANN WSW |
| Orientation | Straight |
| Current | 1A |
| Model | A-DFF 09LPIII/Z-UNC |
| Mount Type | Cable |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Brass |
| Series | AD |
| Termination Type | IDC |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Tin, Nickel, Gold |
| Number of Contacts | 9 |
| Contact Gender | Female |
| Connector Gender | Female |
| Shrouded/Unshrouded | Shrouded |
Key Features
- The connector features a pitch of 2.54mm ensuring compatibility with standard pin spacing.
- Constructed with a brass contact material offering good conductivity.
- The contact plating includes tin, nickel, and gold for enhanced corrosion resistance.
- Designed to operate within a temperature range of -55°C to 105°C.
- The housing material is durable Polybutylene Terephthalate for mechanical stability.
- Termination type is IDC (Insulation Displacement Contact) for efficient cable connections.
- Connector orientation is straight for straightforward installation.
- This AD series connector has female contacts with a shrouded design providing protection.
Product Description
ASSMANN WSW A-DFF 09LPIII/Z-UNC is a high-quality 9-Way IDC Connector designed specifically for cable mounting applications in industrial and electronic environments. Featuring a 2-row, shrouded female connector design, this product ensures secure and reliable cable connections with a pitch of 2.54mm between contacts. Its straight orientation facilitates easy insertion and removal in wiring harness assemblies.
The connector’s 1A current rating and 250V AC voltage compatibility make it suitable for moderate power electronic circuits and signal wiring. Contacts are made from brass and plated with tin, nickel, and gold to provide excellent corrosion resistance and signal integrity over time. The use of Polybutylene Terephthalate as housing material ensures excellent mechanical strength and stability under various environmental conditions.
With an operating temperature range from -55°C to 105°C, the connector supports applications in harsh conditions including industrial equipment, telecommunications, and automation control systems. The insulation displacement contact (IDC) termination type enables fast and efficient cable assembly by eliminating the need to strip wires manually, improving production efficiency.
The connector features a 9-contact female layout arranged in 2 rows. Shrouded housing protects contacts from damage and accidental shorting. Suitable for use in industrial control panels, electronic instrumentation, and communication devices.
This product is designed for professional use and is compliant with relevant industrial standards, although explicit certifications are not indicated. Explore more connectors and electronic components in the Electronics & Electricals category at EnvMart to find complementary products for your application needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector has a voltage rating of 250V AC, making it suitable for moderate power electronic circuits.
This model has a current rating of 1A, which is appropriate for various signal wiring applications.
The contacts are spaced at a pitch of 2.54mm, ensuring compatibility with standard pin spacing.
The contact material is brass, and the housing is made from Polybutylene Terephthalate, providing mechanical stability.
It operates within a temperature range of -55°C to 105°C, suitable for harsh environmental conditions.
This model features a total of 9 contacts arranged in 2 rows, designed for efficient cable connections.
It utilizes an Insulation Displacement Contact (IDC) termination type, which allows for efficient cable assembly without manual wire stripping.
The connector is shrouded, which provides protection for the contacts from damage and accidental shorting.
The connector has a straight orientation, facilitating straightforward installation in wiring harness assemblies.
It is designed for use in industrial control panels, electronic instrumentation, and communication devices.
The country of origin for this connector is China.
It is suitable for moderate power electronic circuits and signal wiring, making it compatible with various industrial and electronic devices.
