XP Power 3 W Isolated DC to High Voltage DC Converter 3kV Output Voltage 15V DC Input E30

XP Power E30 DC/DC Converter is an isolated high voltage DC converter designed for industrial and electronic applications where compact size and efficient power conversion are critical. Featuring a 3kV output voltage and 1 mA output current, this model operates from a 15V DC input voltage with through-hole mounting, making it suitable for PCB assembly in space-constrained environments.

This converter boasts a ComPacT package type that ensures small footprint integration, alongside low ripple and noise performance at 0.25%, minimizing electromagnetic interference (EMI/RFI). Its robust design provides 3.5kV isolation voltage between input and output, allowing safe operation in high voltage scenarios.

Designed to operate reliably in temperatures ranging from -10°C to 60°C, the XP Power E30 features a high MTBF of 2 million hours, ensuring extended operational life and dependability in industrial use.

Typical applications include piezoelectric devices, capacitor charging, igniter or spark modules, field generation, and electrostatic chuck systems, all requiring stable isolated DC voltages.

The unit measures 63.5mm in length, 38.1mm in width, and 21.6mm in depth, with a lightweight gross weight of 85.1 grams, optimized for easy integration on printed circuit boards using through-hole mounting technology.

Small PCB mount package with ComPacT design for space-limited applications. Isolated DC to high voltage DC conversion with 3.5kV isolation voltage. Low leakage current and low ripple with 0.25% ripple and noise level. Input voltage range from 0V DC minimum to 15V DC maximum.

Reliable with a Mean Time Between Failures (MTBF) of 2,000,000 hours. Suitable for piezo devices, capacitor charging, igniter and spark modules, field generation, and electrostatic chuck applications. Compact dimensions: 63.5mm length, 38.1mm width, and 21.6mm depth.

Lightweight converter with approx. 85.1 grams gross weight.

This XP Power DC/DC converter series is ideal for use in industrial, laboratory, manufacturing, and electronic development environments requiring isolated high voltage DC power sources. This product warrants new condition and originates from India as default.
