Texas Instruments Fixed Series Voltage Reference 1.25V ±0.15% 3-Pin SOT-23 REF3312AIDBZT

Free Delivery in India | Lowest Global Shipping Charges

Texas Instruments Fixed Series Voltage Reference 1.25V ±0.15% 3-Pin SOT-23 REF3312AIDBZT

Name: Texas Instruments Fixed Series Voltage Reference 1.25V ±0.15% 3-Pin SOT-23 REF3312AIDBZT
Brand: Texas Instruments
SKU: 203093
Price: 3.13 USD
Availability: InStock



Category Voltage Reference Brand Texas Instruments Condition New

Specifications

Country of Origin	India
Brand	Texas Instruments
Height	1mm
Length	2.92mm
Model	REF3312AIDBZT
Mount Type	Surface
Output type	Fixed
Series	REF3312
Temperature Coefficient	8 ppm/°C
Output Current	5mA
Topology	Series
Maximum Operating Temperature	125°C
Package Type	SOT-23
Load Regulation	50 ppm/mA
Minimum Operating Temperature	-40°C
Reference Type	Fixed
Maximum Input Voltage	7.5V
Line Regulation	50 ppm/V
Minimum Input Voltage	1.45V
Pin Count	3
Reference Voltage	1.25V
Initial Accuracy	±0.15 %

Key Features

This voltage reference features a surface mount SOT-23 package suitable for compact designs.
It operates within a temperature range of -40°C to 125°C ensuring reliability in harsh conditions.
The device offers a low temperature coefficient of 8 ppm/°C for stable voltage performance.
It supports an output current of up to 5 mA with a maximum input voltage of 7.5 V.
Line and load regulations are tightly controlled at 50 ppm/V and 50 ppm/mA respectively for precision applications.
The 3-pin design allows for easy integration in power management circuits.
The REF3312 series is ideal for high accuracy voltage referencing in industrial, instrumentation, and electronics applications.

Product Description

Texas Instruments REF3312AIDBZT is a fixed series voltage reference IC designed for applications requiring precise voltage regulation. It offers a fixed reference voltage of 1.25 V with an initial accuracy of ±0.15%, making it suitable for high-performance power management circuits.

Encapsulated in a compact 3-pin SOT-23 surface-mount package with dimensions approximately 2.92 mm in length and 1 mm in height, this device fits efficiently into tight PCB layouts.

Operating reliably across a wide temperature range from -40°C to 125°C, the REF3312 ensures consistent output even in extreme environments. Its low temperature coefficient of 8 ppm/°C guarantees minimal voltage drift due to temperature variations.

The voltage reference supports output currents up to 5 mA and accepts input voltages ranging between 1.45 V and 7.5 V. It is implemented using a series topology, providing stable fixed output voltage with excellent line regulation of 50 ppm/V and load regulation of 50 ppm/mA.

This product is widely used in industrial instruments, laboratory equipment, and power supply systems where precise and stable voltage references are essential for performance and accuracy.

This voltage reference features a surface mount SOT-23 package suitable for compact designs. It operates within a temperature range of -40°C to 125°C ensuring reliability in harsh conditions. The device offers a low temperature coefficient of 8 ppm/°C for stable voltage performance.

It supports an output current of up to 5 mA with a maximum input voltage of 7.5 V. Line and load regulations are tightly controlled at 50 ppm/V and 50 ppm/mA respectively for precision applications. The 3-pin design allows for easy integration in power management circuits.

The REF3312 series is ideal for high accuracy voltage referencing in industrial, instrumentation, and electronics applications. Consider EnvMart categories and brands to explore more precision Voltage References and semiconductor power management ICs optimized for various industrial and electronic systems.
