Hirose A2 Series Straight Through Hole Pin Header, 1 Contact, 2.54 mm Pitch, 1 Row, Unshrouded A2-1PA-2.54DSA(71)
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 200V |
| Brand | Hirose |
| Orientation | Straight |
| Current | 3A |
| Model | A2-1PA-2.54DSA(71) |
| Mount Type | Through Hole |
| Contact Material | Brass |
| Series | A2 |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 1 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
Key Features
- The connector is unshrouded and supports wire-to-board connection.
- It has a current rating of 3A suitable for standard PCB applications.
- Constructed with brass contact material plated with gold for reliable conductivity.
- Designed for through hole mounting with solder termination.
- Operational temperature range from -55°C to 85°C ensures durability in harsh environments.
- The header has a male contact gender and a row pitch of 2.54 mm.
- Manufactured in Japan with high-quality standards and no shrouded protection.
Product Description
Hirose A2-1PA-2.54DSA(71) Straight Through Hole Pin Header is a precisely engineered wire-to-board connector designed for electronic PCB applications. It is part of the renowned A2 Series known for space-saving high-density pin configurations. This model features a single row of 1 contact with a standard 2.54 mm pitch suitable for efficient PCB interconnections.
The unshrouded design facilitates easy solder termination and inspection while providing reliable electric contact via brass material plated with gold, ensuring excellent conductivity and corrosion resistance. This pin header supports a current rating of 3A and operation within -55°C to 85°C temperature range, making it suitable for a variety of industrial, laboratory, and consumer electronics.
Its through-hole mount type allows sturdy mechanical fastening providing long-term durability. The straight orientation and male contact gender make it compatible with corresponding female connectors in wire-to-board applications. Rated for 200V operation, it ensures safe and stable connectivity in low-voltage systems.
The A2 Series is manufactured in Japan, reflecting high manufacturing quality and compliance with advanced design standards. This connector is widely used in electronics manufacturing, prototyping, and repair, offering dependable performance for signal and power transmission.
The connector is unshrouded and supports wire-to-board connection. It has a current rating of 3A suitable for standard PCB applications. Constructed with brass contact material plated with gold for reliable conductivity.
Designed for through hole mounting with solder termination. Operational temperature range from -55°C to 85°C ensures durability in harsh environments. The header has a male contact gender and a row pitch of 2.54 mm. Voltage rating up to 200V is ideal for low power electronic assemblies.
Manufactured in Japan with high-quality standards and no shrouded protection. Explore the Electronics Components category at EnvMart to find more Hirose connectors and related PCB accessories designed to meet rigorous industry demands.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 3A, making it suitable for standard PCB applications.
The voltage rating for this connector is up to 200V, which is ideal for low power electronic assemblies.
It operates within a temperature range of -55°C to 85°C, ensuring functionality in harsh environments.
The Hirose A2-1PA-2.54DSA(71) is designed for through hole mounting with solder termination.
It features brass as the contact material, which is plated with gold for reliable conductivity and corrosion resistance.
This model has a single row with 1 contact, making it suitable for efficient PCB interconnections.
The pitch for this connector is 2.54 mm, which is standard for many PCB applications.
The contact gender of this model is male, allowing compatibility with corresponding female connectors in wire-to-board applications.
This connector is manufactured in Japan, reflecting high manufacturing quality and standards.
It utilizes a wire-to-board connector system, making it suitable for various electronic applications.
The orientation of the Hirose A2-1PA-2.54DSA(71) is straight, which facilitates easy installation on PCBs.
This model is unshrouded, which allows for easy solder termination and inspection during assembly.
