3M 3000 Series Right Angle Through Hole PCB Header 2.54 mm Pitch 20 Contacts 2 Row Shrouded N3428-5202RB

3M N3428-5202RB 3000 Series Right Angle Through Hole PCB Header offers a superior connection solution for electronic assemblies requiring reliable and compact interconnections. Featuring a precise 2.54 mm pitch and 20 gold-plated copper alloy contacts arranged in 2 rows, this shrouded male header ensures durable and secure board-to-board or wire-to-board connections. Its right angle body orientation optimizes space utilization in crowded PCB layouts, ideal for demanding industrial, consumer electronics, automation systems, and electrical control panel applications.

The solder termination method provides robustness and longevity, guaranteeing stable retention and electrical performance even under thermal and mechanical stresses. The header operates reliably across a wide temperature spectrum from -55°C to 105°C and supports current ratings up to 1.75 A with a voltage withstand of 1000 V, making it suitable for high electrical load applications in challenging environments.

Shrouded design protects against accidental disengagement and mechanical damage, ensuring consistent signal integrity and assembly stability. The 6.2 mm mating pin length and compact two-row configuration facilitate easy mating with compatible connectors and maximize PCB real estate efficiency.

This component is engineered primarily for circuit board interconnection tasks in sectors including industrial instrumentation, manufacturing, consumer electronics, automation, and electrical distribution equipment. Its robust material construction with glass-filled polyester housing guarantees durability and long service life in typical industrial conditions.

2.54 mm pitch enables compatibility across various PCB layouts. Shrouded design enhances connector protection during assembly. Right angle orientation fits tight spaces and optimizes PCB layout. Solder termination ensures durable and reliable electrical connections.

Supports board-to-board and wire-to-board connector systems. Gold plated copper alloy contacts provide excellent conductivity. Operating temperature range from -55°C to 105°C allows versatile application conditions. Rated for 1.75 A current handling in electronic circuits.

Suitable for high voltage applications up to 1000 V. Male contact gender with 6.2 mm mating pin length for secure interconnection.

Set contains 1 piece of 3M 3000 Series Right Angle Through Hole PCB Header, model N3428-5202RB. Designed for use in professional electronic assembly and manufacturing environments.
