HARWIN Datamate L-Tek Series Straight Through Hole PCB Header, 2 Contacts, 2 mm Pitch, 1 Row, Shrouded M80-8520242

Free Delivery in India | Lowest Global Shipping Charges

HARWIN Datamate L-Tek Series Straight Through Hole PCB Header, 2 Contacts, 2 mm Pitch, 1 Row, Shrouded M80-8520242

Name: HARWIN Datamate L-Tek Series Straight Through Hole PCB Header, 2 Contacts, 2 mm Pitch, 1 Row, Shrouded M80-8520242
Brand: HARWIN
SKU: 164682



Category PCB Headers Brand HARWIN Condition New

Specifications

Country of Origin	United Kingdom
Voltage	120V
Brand	HARWIN
Orientation	Straight
Current	3A
Model	M80-8520242
Mount Type	Through Hole
Housing Material	Polyphenylene Sulphide
Contact Material	Phosphor Bronze
Series	Datamate L-Tek
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	2mm
Contact Plating	Gold
Number of Contacts	2
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Board-to-Board, Wire-to-Board
Tail Pin Length	3mm

Key Features

The PCB header supports up to 3A current rating, ensuring stable electrical conductivity.
Constructed with polyphenylene sulphide housing for durability and thermal stability.
Features phosphor bronze contacts plated with gold for enhanced corrosion resistance and signal integrity.
The male contact design includes a 3 mm tail pin length optimized for through-hole mounting.
Operates effectively within a temperature range of -55°C to 125°C for harsh environment applications.
Polarised shrouded design prevents misconnection and improves mating reliability.
Complies with industry standards for robustness, suitable for high vibration and shock conditions.
Mates with industry-standard equivalents, supporting COTS applications.

Product Description

HARWIN M80-8520242 is a high-reliability Datamate L-Tek Series straight through hole PCB header designed for industrial, electronic, and manufacturing applications requiring robust and durable board-to-board or wire-to-board connections.

This connector features a 2 mm pitch, 2 contacts arranged in a single row, and a shrouded housing made from polyphenylene sulphide, providing excellent mechanical strength and resistance to harsh environmental conditions.

The contacts are crafted from phosphor bronze and plated with gold, delivering superior conductivity and corrosion resistance, essential for maintaining signal integrity in demanding use cases.

With a current rating of 3A and a voltage rating of 120V, this PCB header is suited for applications involving moderate power and signal transmission. Its operation span from -55°C to 125°C makes it reliable under wide temperature extremes.

The male contact configuration with a 3 mm solder tail pin length supports through-hole mounting techniques, facilitating secure and stable PCB assembly.

The L-Tek connector's polarised and shrouded design prevents incorrect mating, enhancing system reliability particularly in environments subjected to vibration, shock, or acceleration.

Manufactured in the United Kingdom, this product adheres to high quality and safety standards, although it does not bear specific certifications. The design ensures longevity through high mating cycle endurance enabled by beryllium copper contacts with a four-finger clip.

It complies with BS9525-F0033, MIL C 55302, and CEC 75101-008 standards for connector performance. The connector is ideal for industrial electronics, telecommunications, aerospace, and other high-vibration environments requiring dependable interconnections.

For engineers and procurement specialists, the HARWIN M80-8520242 PCB header offers a trusted solution combining durability, precision, and ease of integration. Explore EnvMart's comprehensive selection of PCB connectors to complement this product and optimize your electronic assemblies.

Explore more products in our PCB Headers category.
