Crydom CW24 Series Solid State Relay Panel Mount 50 A Load 280 Vrms Load 36Vrms Control

The Crydom CW24 Series Solid State Relay CWA2450E is a high-quality industrial panel mount SSR designed to switch heavy electrical loads efficiently and reliably. It can handle a maximum load current of 50 A and a maximum load voltage of 280 Vrms, controlled by an AC control voltage ranging from 18V to 36Vrms.

This solid state relay features zero voltage switching, which significantly reduces electrical noise and enhances energy efficiency during operation. The direct-bond copper substrate construction contributes to superior thermal performance, an essential factor in prolonged operation across demanding industrial, automation, robotics, and medical equipment applications.

Its touchproof IP20-rated enclosure protects users from accidental contact with live terminals while allowing easy visual inspection through its clear cover. The device operates reliably over a wide temperature range of -40°C to +80°C, making it suitable for harsh environments.

The relay uses screw terminals with square washers designed to prevent loosening under vibration, ensuring secure and stable connections in industrial settings. Additionally, its low off-state leakage current of 1mArms and capacitance of 8pF contribute to minimal power losses.

This SSR complies with RoHS and CE standards, ensuring environmental safety and regulatory conformity. Its compact size - 45.7 mm in length, 33 mm in height, and 22 mm in width - makes it ideal for panel mounting in space-constrained control panels or machinery.

Designed for reliable use in harsh industrial and automation settings. Features zero voltage switching for noise reduction and efficiency. Equipped with screw terminal type for secure electrical connection. Wide operating temperature range from -40°C to 80°C ensures durability.

IP20 rated touchproof cover protects against solid objects larger than 12 mm. Compact dimensions: 45.7mm length, 33mm height, and 22mm width optimize panel space. Low off-state leakage current of 1mArms minimizes power loss.

Outputs controlled with SCR technology for stable switching performance. Square washer design prevents loosening under heavy vibration conditions. Complies with RoHS and CE standards for safety and environmental compatibility.

This Solid State Relay is widely applicable in industrial automation systems, HVAC controls, manufacturing machinery, robotics, and medical device controls. Its robustness and precision make it an excellent choice for replacing traditional electromechanical relays, where silent operation and longer lifespan are critical.

Choose this Crydom CW24 Series SSR for dependable, efficient panel mounting relay solutions that require a 50A switching capacity and 280Vrms load voltage. Explore more industrial relays and electrical components at EnvMart for reliable and certified products.
