XP Power Isolated DC/DC Converter 9V DC Output 111mA 21.6-26.4V DC Input 2W SIP7 Through Hole IML02

XP Power IML02 DC/DC Converter is an isolated power supply module providing 9V DC output at 111mA current with a maximum power rating of 2W. It accepts input voltages between 21.6V DC and 26.4V DC, making it suitable for regulated power environments requiring low power DC conversion.

This converter is housed in a SIP7 package with through-hole mounting format, allowing for compact and secure PCB placement in electronic assemblies. With dimensions of 19.5mm length, 12.5mm depth, and 9.8mm width, it integrates easily with limited board space designs.

Featuring a high isolation voltage of 4000 V AC, the IML02 series is designed with medical and industrial grade protection standards in mind, providing enhanced safety and reliability. The device operates efficiently at 77%, reducing energy loss and heat generation in applications.

The output voltage adjustment range of ±5V allows flexibility to fine-tune output for specific application requirements. The converter performs reliably over a wide temperature range from -40°C to 85°C, ensuring robustness in harsh environments.

With a mean time between failures (MTBF) rated at 2,500,000 hours, the XP Power IML02 assures a long operational lifespan for critical systems. The device has no certifications listed but is suitable for worldwide medical applications and other precision industrial uses.

Common industrial applications include power supplies for medical instrumentation, telecommunications, instrumentation and control systems, and other low power DC voltage conversion needs. Its strong isolation and precise output control make it ideal in sensitive and regulated environments.

XP Power is a trusted brand in power supplies, offering reliable, high-quality solutions tailored for demanding electronic components and systems. Browse EnvMart’s Electronics & Electricals section for more power converters and DC supply modules tailored to industrial and commercial requirements.

Operates with an input voltage range from 21.6V to 26.4V DC. Provides dual output channels ensuring versatile power supply options. High isolation voltage of 4000 V AC suitable for demanding medical and industrial environments.

Compact dimensions of 19.5mm length, 12.5mm depth and 9.8mm width for easy PCB integration. Efficient operation at 77% efficiency minimizes thermal losses. Wide operating temperature range from -40°C to +85°C for robust reliability.

SIP7 package construction supports easy through-hole mounting. Offers output voltage adjustment range of ±5V for precise tuning. Long MTBF of 2,500,000 hours demonstrates durable, high-quality design.
