SMC 2 Finger Single Acting Action Pneumatic Gripper, Parallel Gripping Type, Bore Diameter 25mm, Stroke Length 14mm MHZ2-25C

Free Delivery in India | Lowest Global Shipping Charges

SMC 2 Finger Single Acting Action Pneumatic Gripper, Parallel Gripping Type, Bore Diameter 25mm, Stroke Length 14mm MHZ2-25C



Category Pneumatic Gripper Brand SMC Condition New

Specifications

Country of Origin	Japan
Brand	SMC
Maximum Operating Pressure	7 bar
Length	102.7mm
Model	MHZ2-25C
Gross Weight	430g
Series	MHZ
Maximum Operating Temperature	60°C
Port Size	M5
Minimum Operating Temperature	-10°C
Stroke Length	14mm
Bore Diameter	25mm
Action Type	Single Acting
Standards/Approvals	RoHS
Number of Fingers	2
Gripping Type	Parallel
Gripping Force - Internal	83N

Key Features

The gripper utilizes a single acting pneumatic action for reliable operation.
Constructed with a hard anodized aluminium alloy body for enhanced durability.
Includes a linear guide that provides high rigidity and precision accuracy.
Operates at a maximum pressure of 7 bar with a gripping force of 83N internally.
Finger positions are selectable for versatile mounting configurations.
Suitable for industrial applications requiring precise gripping and holding.
Designed to operate within a temperature range from -10°C to 60°C.
Features an M5 port size and a maximum operating frequency of 180 cycles per minute.

Product Description

SMC MHZ2-25C is a high-precision 2 Finger Single Acting Pneumatic Gripper designed with parallel gripping action and a bore diameter of 25mm. It features a stroke length of 14mm, providing effective gripping force of 83N internally. The gripper's body is constructed from hard anodized aluminium alloy, ensuring durability and resistance to wear.

The integral linear guide design enhances rigidity and accuracy, enabling operation under high pressure up to 7 bar, even at larger holding points and overhangs. This pneumatic gripper supports selectable finger positions for flexible mounting and application needs.

Operating efficiently within a temperature range of -10°C to 60°C, it is ideal for use in various industrial automation tasks, including assembly, material handling, and packaging. The M5 port size facilitates pneumatic connections, and it supports a maximum operating frequency of 180 cycles per minute for rapid operation.

The gripper complies with RoHS standards, ensuring environmental safety and reliability. Manufactured in Japan, this pneumatic actuator is suitable for laboratory, manufacturing, construction, and general industrial fluid power applications.

The gripper utilizes a single acting pneumatic mechanism for effective gripping. Equipped with a hard anodized aluminium alloy body for rugged industrial use. The linear guide provides enhanced rigidity for precise gripping control.

Operates with a maximum pressure of 7 bar and a gripping force of 83N internally. Finger positions can be adjusted to suit different operational requirements. Designed for use in a temperature range of -10°C to 60°C for versatile applications.

M5 port size supports solid pneumatic connections for system integration. Maximum operating frequency is 180 cycles per minute, supporting fast process cycles. Explore more products within Pneumatic Grippers category on EnvMart for comprehensive industrial pneumatic tooling solutions.
