XP Power FS Series DC/DC Converter, 2kV Output Voltage, 5mA Output Current, 12V DC Input, Through Hole Mount, 10W FS20-12
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | Converters / DC-DC Converters XP Power FS DC/DC Converter, 2kV/ 5 mA, 12V dc Inp |
| Brand | XP Power |
| Efficiency | 85% |
| Length | 57.15mm |
| Model | FS20-12 |
| Depth | 12.7mm |
| Gross Weight | 45g |
| Width | 28.5mm |
| Mount Type | Through Hole |
| Series | FS |
| Maximum Operating Temperature | 75°C |
| Minimum Operating Temperature | -25°C |
| MTBF | 840000h |
| Number of outputs | 1 |
| Ripple and Noise | 2.5% Pk-Pk |
| Maximum Output Power | 10W |
| Maximum Input Voltage | 12V dc |
| Minimum Input Voltage | 0V dc |
| Output Voltage 1 | 2kV |
| Output Current 1 | 5mA |
| Isolation Voltage | 2.5kV |
Key Features
- Operates with a 12V DC input voltage and 0V minimum input.
- Features through hole mounting for easy installation.
- Provides a maximum output current of 5mA with 2kV output voltage.
- Rated maximum output power of 10 watts for efficient energy conversion.
- Operating temperature range from -25°C to 75°C for versatile use.
- High isolation voltage of 2.5kV ensuring electrical safety.
- Includes low ripple and noise of 2.5% peak-to-peak for clean output.
- Built-in robustness with an MTBF of 840,000 hours indicating high reliability.
Product Description
XP Power FS20-12 is a high-performance DC/DC converter designed to provide isolated DC to high voltage DC conversion with a robust and reliable design. This FS Series converter features a 2kV output voltage and operates from a 12V DC input, making it suitable for a wide range of industrial, laboratory, and electronic applications where stable and clean high voltage is required.
The through hole mount type facilitates secure PCB installation, while the compact dimensions of 57.15mm length, 28.5mm width, and 12.7mm depth allow integration in space-limited designs. Operating from -25°C to 75°C, the converter is well suited to operate in diverse environments.
This product delivers up to 10 watts of output power with an output current of 5mA, and provides high isolation voltage of 2.5kV, enhancing safety and performance. The ripple and noise is maintained low at 2.5% peak-to-peak, ensuring excellent signal quality for sensitive equipment.
With an MTBF of 840,000 hours, the FS20-12 guarantees long-term reliability and durability in demanding conditions. Manufactured in the United States, this DC/DC converter conforms to high quality manufacturing standards to serve electronics, telecommunications, medical, and industrial power supply needs.
Operates with a 12V DC input and 0V minimum input voltage. Provides a stable 2kV output voltage at 5mA output current. Through hole mounting for easy PCB integration. Maximum output power of 10 W suitable for moderate load applications.
Operating temperature range of -25°C to 75°C supports harsh environments. Low ripple and noise of 2.5% Pk-Pk for clean output power. High isolation voltage of 2.5kV enhances safety and noise immunity. Compact size with 57.15mm (L) x 28.5mm (W) x 12.7mm (D).
Designed with reliability, boasting 840,000 hours MTBF. Ideal for industrial, laboratory, telecommunications, and medical applications. Explore full range of DC/DC Converters and power supplies on EnvMart for reliable power conversion components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output voltage of this model is 2kV.
It operates with a minimum input voltage of 0V and a maximum input voltage of 12V DC.
The output current rating is 5mA.
The maximum output power is 10 watts.
The dimensions are 57.15mm in length, 28.5mm in width, and 12.7mm in depth.
It operates within a temperature range of -25°C to 75°C.
This model features through hole mounting for easy installation on PCBs.
The isolation voltage is rated at 2.5kV, enhancing safety and performance.
The ripple and noise is maintained at 2.5% peak-to-peak.
The mean time between failures (MTBF) is 840,000 hours, indicating high reliability.
The efficiency rating of this DC/DC converter is 85%.
This model is manufactured in the United States.
