XP Power Isolated Miniature DC/DC Converter, 400V DC Output, 5V DC Input, 1W Power, Through Hole Mount, Model A04P-5

XP Power A04P-5 is an isolated DC/DC converter delivering 400V DC output power from a 5V DC input source at 1W. Designed for ultra miniature high voltage isolation needs, it is built with through-hole mounting for secure and reliable PCB integration. The converter operates between temperatures of -25°C and 75°C, allowing use in a wide range of industrial, laboratory, and instrumentation environments.

This model provides galvanic isolation of 500V and features low output/input capacitance to minimize interference in sensitive circuits. With a maximum output current of 2.5mA and low ripple and noise of 0.5% peak-to-peak, it ensures stable and clean power suitable for precision electronics like avalanche photodiodes, photomultiplier tubes, electrophoresis apparatus, sustaining ion pumps, piezo devices, and capacitor charging.

Designed in the A series, XP Power’s converter includes a quasi-sinewave oscillator and current low leakage control pin with external component-free design. It also protects against short circuits for at least one minute and requires no minimum load to operate effectively. These features are essential in scientific, medical, and industrial applications where isolated high voltage power conversion is critical.

The converter’s compact size of 23.37mm x 11.43mm x 6.35mm and light weight of 5.7g make it a space-saving solution for embedded systems and high-density electronics assemblies. With a mean time between failures (MTBF) of over 1.8 million hours, it offers long-term durability and reliability.

Minium operating temperature is -25°C and maximum operating temperature is 75°C. Supports galvanic isolation with 500V isolation voltage. Output current is 2.5mA with low ripple and noise at 0.5% peak-to-peak. Mount type is through hole for easy PCB integration.

Provides 1 minute minimum short circuit protection for robust operation. Extremely low output/input capacitance ensures high efficiency and low interference. Ideal for use with avalanche photodiodes, photomultiplier tubes, piezo and capacitor charging applications.

Measures 23.37mm length, 11.43mm width, and 6.35mm depth with a weight of 5.7g. MTBF of 1,862,000 hours indicates high reliability for industrial applications.

This XP Power DC/DC converter is suitable for use in medical instrumentation, industrial controls, water treatment systems, scientific instrumentation, and aerospace or defense electronics. Its ultra-compact design allows integration into space constrained and high voltage isolated power applications.
