SMC Pneumatic Compact Cylinder 6mm Bore, 30mm Stroke, Aluminium Alloy Body, Double Acting, Through Hole Mount CXSJM6-30

Free Delivery in India | Lowest Global Shipping Charges

SMC Pneumatic Compact Cylinder 6mm Bore, 30mm Stroke, Aluminium Alloy Body, Double Acting, Through Hole Mount CXSJM6-30



Category Pneumatic Cylinder Brand SMC Condition New

Specifications

Country of Origin	India
Brand	SMC
Body Material	Aluminium Alloy
Maximum Operating Pressure	0.7 Mpa
Model	CXSJM6-30
Gross Weight	70g
Mount Type	Through Hole
Series	CXS
Maximum Operating Temperature	60°C
Minimum Operating Temperature	-10°C
Stroke Length	30mm
Bore Diameter	6mm
Rod Type	Double
Action Type	Double Acting
Cushioning Type	Rubber Bumper
Piston Rod Thread Standard	Metric
Piston Rod Thread Size	M3

Key Features

Features through hole mount for secure attachment.
Equipped with rubber bumper cushioning to reduce impact.
Operates within a maximum pressure of 0.7 Mpa for reliability.
Supports double rod type design for balanced operation.
Suitable for operating temperature range from -10°C to 60°C.
Piston rod with M3 metric thread size for compatibility.
Compact and lightweight, weighing 70g for easy integration.
Designed for industrial automation and fluid power control systems.

Product Description

SMC CXSJM6-30 Pneumatic Compact Cylinder features a 6mm bore and 30mm stroke length, constructed with durable aluminium alloy body suitable for pneumatic systems requiring precise linear motion. This double acting cylinder utilizes a double rod design to provide balanced operation and enhanced stability in various industrial automation applications.

It has a through hole mounting type allowing for secure and versatile installation options. The integration of rubber bumper cushioning ensures shock absorption and extends cylinder life by reducing impact stresses. The unit operates safely under a maximum pressure of 0.7 Mpa and supports maximum piston speeds up to 700 mm/s, making it suitable for high-speed pneumatic controls.

The piston rod is threaded with a metric M3 standard for easy attachment of tooling or mechanical linkages. This cylinder operates effectively within a temperature range of -10°C to 60°C, making it adaptable to diverse environmental conditions in manufacturing, laboratory, and commercial automation sectors.

Its compact size and lightweight design at 70 grams enable use in applications with space constraints or where weight reduction is critical. The auto switch mounting groove allows for seamless integration of sensors for position detection and process monitoring.

This cylinder is ideal for use in industrial pneumatic systems, manufacturing equipment, fluid power assemblies, and automation tasks where precise and reliable linear actuation is essential.

Features through hole mount for secure attachment. Equipped with rubber bumper cushioning to reduce impact. Operates within a maximum pressure of 0.7 Mpa for reliability. Supports double rod type design for balanced operation.

Suitable for operating temperature range from -10°C to 60°C. Piston rod with M3 metric thread size for compatibility. Compact and lightweight, weighing 70g for easy integration. Designed for industrial automation and fluid power control systems.

Includes auto switch mounting groove for sensor integration. Explore more Pneumatic Cylinders and actuators from SMC to suit applications in industrial automation, manufacturing, and fluid control systems on EnvMart.
