Murata Power Solutions Series 1W Isolated DC/DC Converter, 12V Output, 21.6V-26.4V Input, Through Hole, 85°C Max CRL2

Murata Power Solutions CRL2S0505SC DC/DC Converter is a compact, isolated power module designed to convert DC voltages efficiently within electronic systems. It provides a regulated 12V output from a wide input range between 21.6V and 26.4V, making it highly suitable for applications requiring stable power conversion with galvanic isolation.

The converter features through hole mounting with a standard SC package, ensuring compatibility with industry designs and ease of integration into printed circuit boards. Operating reliably across a temperature range from -40°C to 85°C, it supports demanding industrial, laboratory, and commercial environments.

This 1 watt converter delivers single isolated output and maintains high efficiency of 78%, with low ripple and noise (25mV Pk-Pk) to preserve signal quality. The device is fully encapsulated and uses toroidal magnetics instead of electrolytic or tantalum capacitors, enhancing durability and longevity under continuous operation.

Key technical advantages include an isolation voltage rating of 1kV dc, 8-pin configuration, and a lightweight form factor of only 1.38 grams. The small dimensions (14mm length, 7.5mm width, 10mm depth) facilitate dense component packing in compact electronic assemblies.

Murata's CRL2 series supports seamless upgrades from other series like NME and LME due to matched pinouts. The converters are ideal for electrical isolation tasks, negative rail installations, and stable DC power rail conversions commonly required in instrumentation, telecommunications, control systems, and other industrial applications.

Single isolated output with industry standard pin compatibility enables easy upgrade. Through hole mounting package type SC for reliable PCB integration. Wide operating temperature range from -40°C to 85°C suitable for various industrial environments.

High isolation voltage of 1kV dc ensures electrical safety and noise reduction. Low ripple and noise at 25mV peak-to-peak enhances signal integrity. Compact dimensions with length 14mm, width 7.5mm, depth 10mm and very light weight of 1.38g.

Efficiency rated at 78% for effective power conversion. No electrolytic or tantalum capacitors improve product reliability. Fully encapsulated with toroidal magnetics for durable performance.

The Murata CRL2S0505SC 1W DC/DC converter is a robust solution for industrial, laboratory, construction, and commercial applications requiring reliable DC power conversion with galvanic isolation. It offers excellent thermal stability, high safety standards, and long-term operational reliability. Browse EnvMart's wide range of DC/DC Converters for complementary industrial power solutions.
