XP Power Isolated DC/DC Converter 24 V DC Output 250 mA 72 V DC Input 36 V Input 6 W Through Hole JCD0648S24
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters XP Power JCD DC/DC Converter, 24V dc/ 250 mA, 72V |
| Brand | XP Power |
| Efficiency | 85% |
| Length | 31.75mm |
| Model | JCD0648S24 |
| Depth | 10.4mm |
| Width | 20.32mm |
| Mount Type | Through Hole |
| Series | JCD |
| Maximum Operating Temperature | 100°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| MTBF | 1100000h |
| Number of outputs | 1 |
| Maximum Output Power | 6W |
| Maximum Input Voltage | 72V dc |
| Standards/Approvals | RoHS |
| Minimum Input Voltage | 36V |
| Number of Pins | 24 |
| Output Voltage 1 | 24V dc |
| Output Current 1 | 250mA |
| Isolation Voltage | 1.6kV dc |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
Key Features
- This converter delivers a maximum output power of 6 watts with high efficiency up to 85 percent.
- The 24-pin DIP package is designed for through-hole mounting on PCBs for robust electrical connections.
- Operating temperature ranges from -40 °C to +100 °C supports use in harsh industrial environments.
- The device provides 1.6 kV DC isolation voltage ensuring safety and noise reduction in circuits.
- The JCD series supports continuous short circuit protection enhancing reliability in application.
- Compact dimensions of 31.75 mm length, 20.32 mm width, and 10.4 mm depth suit space-constrained designs.
- Mean Time Between Failures (MTBF) is rated at 1,100,000 hours indicating high operational reliability.
- Compliance with RoHS standards ensures environmental and safety compliance.
Product Description
XP Power's JCD0648S24 is a high-performance isolated DC/DC converter ideal for conversion applications requiring stable 24 V DC output at a current of 250 mA. Its input voltage capability ranges from 36 V to 72 V DC, supporting a 2:1 input voltage ratio which accommodates wide input variations common in industrial and electronic applications.
Encased in a 24-pin DIP package designed for through-hole mounting, this converter provides ease of integration onto printed circuit boards with secure mechanical and electrical contacts. Its compact size of 31.75 mm by 20.32 mm by 10.4 mm allows integration even in space-restricted assemblies.
With a maximum output power rating of 6 W and an efficiency of up to 85%, the JCD0648S24 delivers reliable performance with minimal power losses. The device offers continuous short circuit protection which enhances system reliability and safety. Thermal operating limits extend from -40 °C to +100 °C permitting use in a variety of demanding environments, including industrial, telecommunication, and instrumentation systems.
This model delivers high isolation with 1.6 kV DC between input and output, critical for protecting low voltage circuits and ensuring signal integrity. The JCD series is renowned for its high mean time between failures (MTBF) of 1,100,000 hours, emphasizing ruggedness and longevity in operation.
Maximum output power of 6 W with up to 85% efficiency. Wide 2:1 input voltage range from 36 V to 72 V DC. 24-pin DIP package for through-hole mounting. Operating temperature range of -40 °C to +100 °C. High isolation voltage of 1.6 kV DC for safety.
Continuous short circuit protection enhances reliability. Compact size ensures easy PCB integration. MTBF rating of 1,100,000 hours for durable use. RoHS compliant for environmental safety. Manufactured in Taiwan, Province Of China.
This converter is well-suited for use in electronic components, power supplies & transformers, industrial automation, telecommunications equipment, medical instrumentation, and other applications requiring reliable DC power conversion.
Explore the full range of XP Power DC/DC Converters at EnvMart for solutions tailored to industrial and electronic design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output power of this model is 6 watts.
It supports an input voltage range from 36 V to 72 V DC.
The converter operates with an efficiency of up to 85%.
The dimensions are 31.75 mm in length, 20.32 mm in width, and 10.4 mm in depth.
It is designed for through-hole mounting on PCBs.
The operating temperature range extends from -40 °C to +100 °C.
It provides an isolation voltage of 1.6 kV DC between input and output.
It includes continuous short circuit protection to enhance reliability.
The MTBF is rated at 1,100,000 hours.
Yes, it is RoHS compliant, ensuring environmental and safety compliance.
It is suitable for applications in industrial automation, telecommunications equipment, and medical instrumentation.
This model has one output rated at 24 V DC and 250 mA.
