STMicroelectronics 1-Element Bi-Directional TVS Diode, Surface Mount SMC Package, 1.5 kW, 2-Pin SM15T220CA

STMicroelectronics SM15T220CA is a high-performance 1-element bidirectional Transient Voltage Suppressor (TVS) diode designed for surface mounting in the compact SMC package. It offers robust protection for electronic circuits against voltage spikes and transient surges up to 1.5 kW peak pulse power dissipation. This diode is constructed to ensure stable bidirectional suppression, making it ideal for protecting sensitive semiconductor devices in industrial, automotive, and commercial applications.

The component features a minimum breakdown voltage of 209 V and can withstand a maximum reverse stand-off voltage of 188 V. Its clamping voltage at peak pulse current reaches 388 V, providing effective transient voltage suppression. The TVS diode supports peak pulse current ratings of 26 A and maintains a very low reverse leakage current of 1 μA, which contributes to low power losses.

Mechanical dimensions are compact with a length of 7.15 mm, width of 6.25 mm, and height of 2.45 mm, facilitating easy integration into circuit designs. It functions over a wide temperature range from -55°C up to 150°C, ensuring reliable performance in harsh environments. The 2-pin design simplifies board layout and contributes to efficient assembly processes.

This product is suitable for use in electronic component protection such as power supplies, automotive electronics, industrial controllers, and telecommunications equipment. Its surface mount configuration helps optimize board space while offering effective transient voltage protection.

Designed for bidirectional transient voltage suppression protecting sensitive electronics. Features a single diode element optimized for effective voltage clamping. Supports a minimum breakdown voltage of 209 V and maximum reverse stand-off voltage of 188 V.

Compact surface mount SMC package dimensions: 7.15mm length, 6.25mm width, 2.45mm height. Capable of withstanding peak pulse current up to 26 A with a clamping voltage of 388 V. Operates reliably across -55°C to 150°C temperature range.

Low maximum reverse leakage current of 1 μA enhances efficiency and device stability. Designed to meet demanding industrial and commercial electronic circuit protection requirements. Explore more high-quality semiconductor components and TVS Diodes within EnvMart's extensive catalog for electronics protection solutions.
