STMicroelectronics 1-Element Bi-Directional TVS Diode 1.5 kW Power Dissipation, 2-Pin Through Hole 1.5KE Series 1.5KE62CA

STMicroelectronics 1.5KE62CA is a 1-element bi-directional Transient Voltage Suppressor (TVS) diode designed for protecting sensitive electronics from voltage spikes and transient surges. It dissipates peak pulse power of 1.5 kW, making it suitable for high-reliability industrial and electronic circuit applications.

The diode features a single bi-directional configuration with a through-hole mounting style and 2-pin axial leads. Its 1.5KE series package allows for compact and rugged integration onto PCBs. The device operates reliably across a wide temperature range from -65°C minimum up to 175°C maximum, ensuring stable performance in demanding environmental conditions.

The key electrical characteristics include a minimum breakdown voltage of 58.9 V, a maximum reverse stand-off voltage of 53 V, and a clamping voltage of 111 V during transient events. It can handle a maximum peak pulse current of 90 A, providing effective protection against damaging voltage spikes commonly encountered in industrial, automotive, and communication electronics.

Physically, the diode measures 5.3 mm in diameter and width, with a length of 9.5 mm, allowing for versatile placement in compact assemblies. This TVS diode is essential for safeguarding circuits by shunting high transient voltages away from sensitive components, enhancing device longevity and reliability.

Typical applications include power supply circuits, industrial control systems, automotive electronics, and other equipment requiring robust surge protection. Single diode configuration providing bi-directional voltage protection.

Peak pulse power dissipation of 1.5 kW for enhanced circuit safeguarding. Through hole mounting with 2 pins for robust installation. Package type 1.5KE offering reliable axial leaded format. Operates within a wide temperature range from -65°C to 175°C.

Minimum breakdown voltage of 58.9 V and maximum reverse stand-off voltage of 53 V. Clamping voltage of 111 V ensuring effective transient suppression. Maximum peak pulse current of 90 A suited for high transient events. Compact size with 5.3 mm diameter and width, and 9.5 mm length.

Designed for industrial electronic component applications requiring transient voltage protection. Explore more TVS Diode products and comprehensive electronics components at EnvMart for reliable industrial, manufacturing, and electronic circuit protection solutions.
