XP Power DC/DC Converter Through Hole 15V DC 400 mA 6 W 18V DC Input JCA0612S15
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters XP Power JCA DC/DC Converter, 15V dc/ 400 mA, 18V |
| Brand | XP Power |
| Efficiency | 85% |
| Length | 25.4mm |
| Model | JCA0612S15 |
| Depth | 10mm |
| Width | 20.3mm |
| Mount Type | Through Hole |
| Series | JCA |
| Maximum Operating Temperature | 100°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| MTBF | 1000000h |
| Number of outputs | 1 |
| Maximum Output Power | 6W |
| Maximum Input Voltage | 18V dc |
| Minimum Input Voltage | 9V |
| Number of Pins | 24 |
| Output Voltage 1 | 15V dc |
| Output Current 1 | 400mA |
| Isolation Voltage | 1.5kV dc |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
Key Features
- Compact through-hole DIP package measuring 25.4 mm length, 20.3 mm width, and 10 mm depth.
- Operates efficiently with up to 85% efficiency within a wide temperature range from -40°C to 100°C.
- Offers high isolation voltage of 1.5 kV DC for reliable electrical separation between input and output.
- Designed for single output power conversion with 24 pins for mounting and connection.
- Robust product with a mean time between failures (MTBF) of 1,000,000 hours ensuring long-term reliability.
Product Description
XP Power JCA0612S15 is a high-efficiency DC/DC converter designed for power supply applications requiring 15 V DC output at 400 mA. This through-hole mounted DIP package converter supports input voltages ranging from 9 V to 18 V DC, enabling it to operate flexibly within a 2:1 input ratio.
The compact package dimensions of 25.4 mm length, 20.3 mm width, and 10 mm depth allow for integration in tight PCB layouts. With a maximum output power of 6 W and efficiency rated at 85%, it delivers efficient power conversion in industrial and electronic equipment.
Operating over a wide temperature range from -40°C to 100°C, the converter is suitable for harsh environments. It provides electrical isolation rated at 1.5 kV DC from input to output, enhancing system safety.
The device features 24 pins arranged in a standard DIP package, meeting industry-standard pin outs for easy replacement and design integration. Its high reliability is supported by a MTBF of 1,000,000 hours, making it ideal for demanding industrial, communication, and instrumentation applications.
Compact through-hole DIP package of 25.4 x 20.3 x 10 mm dimensions. 85% efficiency ensuring reduced heat generation and energy savings. Wide operating temperature from -40°C to 100°C for versatile environments. High isolation voltage of 1.5 kV DC supports safe electrical separation.
Single output with 15 V DC at 400 mA maximum current.
XP Power JCA0612S15 fits applications in electronic component power supplies, industrial control, instrumentation, and communication systems requiring reliable DC/DC power conversion.
Explore the full range of DC/DC Converters available at EnvMart for your power supply design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides an output voltage of 15V DC with a maximum output current of 400mA.
The converter operates with an efficiency of 85%, ensuring reduced heat generation and energy savings.
It supports input voltages ranging from 9V to 18V DC, allowing for flexible operation within a 2:1 input ratio.
The compact dimensions of this unit are 25.4mm in length, 20.3mm in width, and 10mm in depth.
It features a high isolation voltage of 1.5kV DC, providing reliable electrical separation between input and output.
The device operates efficiently over a wide temperature range from -40°C to 100°C, suitable for harsh environments.
This model is designed for a single output power conversion.
It has a mean time between failures (MTBF) of 1,000,000 hours, indicating high reliability.
This unit is designed for through-hole mounting, featuring a standard DIP package.
It is suitable for applications in electronic component power supplies, industrial control, instrumentation, and communication systems.
The converter features 24 pins arranged in a standard DIP package for mounting and connection.
This model is part of the JCA series of DC/DC converters from XP Power.
