STMicroelectronics 1-Element Bi-Directional TVS Diode, Surface Mount, 600 W Peak Pulse Power, 2-Pin DO-214 SM6T7V5CA
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 2.45mm |
| Length | 4.6mm |
| Model | SM6T7V5CA |
| Width | 3.95mm |
| Mount Type | Surface |
| Series | SM6T |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 14.5V |
| Diode Configuration | Single |
| Direction Type | Bi-Directional |
| Minimum Breakdown Voltage Vbr | 7.13V |
| Maximum Reverse Stand-off Voltage Vwm | 6.4V |
| Peak Pulse Power Dissipation Pppm | 600W |
| Test Current It | 10mA |
| Maximum Peak Pulse Current Ippm | 276A |
| Maximum Reverse Leakage Current | 20μA |
Key Features
- Bi-directional diode configuration for effective transient voltage suppression.
- Surface mount design suitable for compact PCB layouts.
- Peak pulse power rating of 600 W ensures robust protection.
- Wide operating temperature range from -55°C to 150°C.
- Low maximum reverse leakage current of 20μA for energy efficiency.
- Clamping voltage of 14.5 V for precise voltage control.
- Compact dimensions of 4.6 mm length, 3.95 mm width, and 2.45 mm height.
- Test current of 10 mA and max peak pulse current of 276 A for reliable transient handling.
Product Description
STMicroelectronics SM6T7V5CA is a single-element bi-directional TVS diode designed for transient voltage suppression with a peak pulse power dissipation of 600 W. Housed in a 2-pin DO-214 surface mount package, this diode provides robust protection for electronic circuits against voltage spikes and surges commonly encountered in industrial and consumer electronics applications.
The device offers a minimum breakdown voltage of 7.13 V and a maximum reverse stand-off voltage of 6.4 V, ensuring precise voltage clamping at transients up to 14.5 V. Its low leakage current of 20μA and the ability to operate in a wide temperature range from -55°C to 150°C make it suitable for harsh environments including automotive and industrial electronics.
With compact physical dimensions of 4.6 mm length, 3.95 mm width, and 2.45 mm height, the SM6T7V5CA diode fits well in space-constrained applications, facilitating efficient PCB layout designs. Its tested parameters include a test current of 10 mA and a maximum peak pulse current of 276 A, guaranteeing durability and operational reliability in transient voltage suppression tasks.
This STMicroelectronics TVS diode is ideal for protecting sensitive components in power supplies, telecommunications equipment, industrial control systems, and consumer electronics. The surface mount design enables automated assembly processes, improving manufacturing efficiency.
Set contains 1 Pc of SM6T7V5CA TVS Diode. Bi-directional diode configuration for effective transient voltage suppression. Surface mount design suitable for compact PCB layouts. Peak pulse power rating of 600 W ensures robust protection.
Wide operating temperature range from -55°C to 150°C. Low maximum reverse leakage current of 20μA for energy efficiency. Clamping voltage of 14.5 V for precise voltage control. Compact dimensions of 4.6 mm length, 3.95 mm width, and 2.45 mm height.
Test current of 10 mA and max peak pulse current of 276 A for reliable transient handling. Explore more semiconductor and diode components on EnvMart to find solutions tailored for industrial, automotive, and consumer electronic applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The peak pulse power rating of the SM6T7V5CA is 600 W, providing robust protection against voltage spikes.
This model has compact dimensions of 4.6 mm in length, 3.95 mm in width, and 2.45 mm in height, making it suitable for space-constrained applications.
The maximum operating temperature for this diode is 150°C, allowing it to function in harsh environments.
The clamping voltage of the SM6T7V5CA is 14.5 V, ensuring precise voltage control during transients.
The maximum reverse leakage current for the SM6T7V5CA is 20μA, contributing to its energy efficiency.
The test current for the SM6T7V5CA is 10 mA, which is part of its operational reliability in transient handling.
This diode can handle a maximum peak pulse current of 276 A, ensuring reliable performance during voltage transients.
The minimum breakdown voltage of this diode is 7.13 V, providing effective transient voltage suppression.
The SM6T7V5CA uses a surface mount design, which is suitable for compact PCB layouts and automated assembly processes.
This model features a single-element bi-directional diode configuration, designed for effective transient voltage suppression.
The minimum operating temperature for the SM6T7V5CA is -55°C, allowing it to be used in a wide range of environments.
This TVS diode is suitable for protecting sensitive components in power supplies, telecommunications equipment, industrial control systems, and consumer electronics.
