Wurth Elektronik 385 Series Pluggable Terminal Block 4-Contact 5 mm Pitch 1 Row 691385700004

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik 385 Series Pluggable Terminal Block 4-Contact 5 mm Pitch 1 Row 691385700004

Name: Wurth Elektronik 385 Series Pluggable Terminal Block 4-Contact 5 mm Pitch 1 Row 691385700004
Brand: Wurth Elektronik
SKU: 189026



Category Pluggable Terminal Blocks Brand Wurth Elektronik Condition New

Specifications

Country of Origin	India
Voltage	300V ac
Brand	Wurth Elektronik
Colour	Grey
Orientation	Vertical
Current	16A
Length	20mm
Depth	15.5mm
Width	16mm
Housing Material	Polyamide
Series	385
Number of Rows	1
Pitch	5mm
Number of Contacts	4
Connector Gender	Female
Minimum Wire Size mm²	0.2mm²
Maximum Wire Size mm²	3.31mm²
Minimum Wire Size AWG	24AWG
Maximum Wire Size AWG	12AWG
Wire Connection Method	Cable

Key Features

The terminal block is rated for a current of 16 A at 300 V ac voltage.
Constructed with a durable polyamide housing in grey color ensuring safe insulation.
Suitable wire sizes range from 0.2 mm² to 3.31 mm² (24 AWG to 12 AWG), catering to varied connection requirements.
The connector features a female gender and supports cable wire connection method.
Measuring 20 mm in length, 16 mm in width, and 15.5 mm in depth for compact installation.
The terminal uses an M2.5 screw for secure conductor termination.
Orientation is vertical, ideal for standard PCB mounting and wiring layouts.

Product Description

Wurth Elektronik 691385700004 is a 385 Series pluggable terminal block engineered for reliable and efficient electrical connections. Featuring 4 contacts with a 5 mm pitch and a single-row layout, this terminal block provides a compact footprint suited for a wide range of electronic and electrical applications.

The housing material is polyamide, known for its excellent mechanical strength and electrical insulation properties. Its grey color meets standard industry preferences and the design conforms to UL94-V0 fire safety standards.

Electrical specifications include a current rating of 16 A and an AC voltage rating of 300 V, accommodating moderate power requirements in industrial, commercial, and electronic device contexts. The terminal block supports wire sizes from 0.2 mm² to 3.31 mm² (equivalent to 24 AWG to 12 AWG), ensuring compatibility with various cable gauges.

Connection is accomplished via an M2.5 screw terminal, ensuring a secure and vibration-resistant conductor attachment. The vertical orientation facilitates ease of assembly on PCBs or terminal strips, optimizing space usage.

This model measures 20 mm in length, 16 mm in width, and 15.5 mm in depth, making it suitable for compact electrical panels and control equipment. The plug connector is part of Wurth Elektronik's 385 series, known for modularity and reliability.

The terminal block allows for quick disassembly and modular configurations in circuit designs. Its construction supports application in industrial automation, HVAC systems, power control panels, and electronic instrumentation.

Designed to withstand harsh environments making it suitable for rugged industrial operations. Easy to handle and install, facilitating maintenance and upgrades. The pluggable design supports replacement or reconfiguration without soldering.

This product is ideal for engineers and technicians seeking robust pluggable terminals for varied electronic and electrical assemblies. Discover more products in the Pluggable Terminal Blocks category at EnvMart to fulfill all your electronic connection requirements.
