Dold Multi-function DIN Rail Timer Relay 1-Contact 240V AC 0.02s-300h IK7817N.81/200 AC/DC12-240V 0.02s-300h

Dold IK7817N.81/200 AC/DC12-240V 0.02s-300h is a compact multifunction DIN rail timer relay designed for high precision in industrial automation systems. It supports a broad supply voltage range from 12V AC/DC to 240V AC/DC, making it versatile for numerous control applications.

This timer relay offers eight selectable time ranges extending from 0.06 seconds up to 300 hours, configurable via rotary switches. Its multifunction capabilities include delay on energisation, fleeting on make, delay pulse, flasher, start with pulse, delay on de-energisation, pulse forming, cyclic timer, and other advanced timing functions tailored for process control industries.

Constructed with a robust SPDT relay contact rated at 3A and a switching voltage of 230V, the relay provides reliable contact performance. Installation is simplified by the DIN rail mounting and screw terminal connections which comply with DIN 43880 standards. The device’s compact dimensions (17.5 mm width, 84 mm height, and 90 mm length) enable it to fit easily within industrial distribution panels.

LED indicators on the front panel provide clear visual feedback on operational status, contact position, and timing, facilitating easy monitoring and adjustment. The unit features an adjustment aid for quick setting of long-time values and supports 2-wire proximity sensor control with a connection option for a remote 10 kOhm potentiometer.

The operating temperature range from -40°C to +60°C and the IP40 rated housing ensure the timer relay's durability in demanding industrial environments. Certifications include CE conformity and compliance with IEC/EN standards such as IEC/EN 60947-5-1, IEC/EN 61000 series, and IEC/EN 60255 series, ensuring it meets stringent industrial safety and EMI requirements.

Applications span textiles, chemical processing, mining, irrigation systems, raw material handling, food and beverage processing, and general industrial process control. This multifunction timer relay combines low cost with high performance, making it suitable for a wide range of automation tasks.

Operates with a voltage range from 12V AC/DC to 240V AC/DC. Provides multifunction timing functions with selectable time ranges from 0.03 minutes to 300 hours. Features 1 SPDT contact rated at 3A and 230V switching voltage.

Compact DIN rail mounting with a width of 17.5 mm for easy installation. Durable screw terminal connections compatible with industrial distribution systems. Equipped with LED indicators showing operation status, contact position, and time delay.

Operating temperature range from -40°C to 60°C supports harsh industrial environments. CE certified and complies with IEC/EN standards ensuring reliability and safety. Ideal for process control in mining, chemical, textile, irrigation, food and beverage industries.
