RS PRO DIN Rail Timer Relay, 1-Contact, Multifunction Timer, 240 V DC, 12 V AC & 240 V AC Supply, 0.1 Seconds to 896-6813

Name: RS PRO DIN Rail Timer Relay, 1-Contact, Multifunction Timer, 240 V DC, 12 V AC & 240 V AC Supply, 0.1 Seconds to 896-6813
Brand: RS PRO
SKU: 135864
Price: 45.07 USD
Availability: InStock



Category Timer Relays Brand RS PRO Condition New

Specifications

Country of Origin	India
Brand	RS PRO
Height	65mm
Function	Timer
Length	85mm
Model	896-6813
Mode	Multifunction
Width	18mm
Mount Type	DIN Rail
Series	RS PRO
Maximum Operating Temperature	60°C
Contact Configuration	CO
Minimum Operating Temperature	-10°C
Time Range	0.1 s to 100 h
Terminal type	Screw
Standards/Approvals	RoHS
Number of Contacts	1
Number of Timer Functions	Multifunction
Contact Current	5A
Supply DC Voltage	240 V dc
Timing Adjustment	Knob
Supply AC Voltage	12, 240V ac

Key Features

This timer relay supports both 240 V DC and 12/240 V AC supply voltages.
It has a compact 17.5 mm width suitable for tight DIN rail mounting installations.
The relay offers 10 multifunctional time modes selectable via an easy-to-use front knob.
Equipped with LED indicators to show power and relay status clearly.
Designed for industrial use with operating temperatures from -10°C to 60°C and IP20 terminal protection.
The relay provides a 5 A contact current capacity with CO switch contact configuration.
Screw terminal type ensures secure and reliable wiring connections.
Standards compliant with RoHS and manufactured in India.

Product Description

RS PRO 896-6813 DIN Rail Timer Relay is a multifunction timer relay designed for precise and reliable time delay applications in electrical and automation systems. This model offers a 1-contact configuration with multifunctional timing modes ranging from 0.1 seconds to 100 hours, adaptable for multiple industrial timing requirements.

It supports a wide supply voltage range including 240 V DC and 12 to 240 V AC, enabling flexible integration in various power management setups. The compact 17.5 mm DIN rail mount design saves space and allows easy installation in electrical enclosures and control panels.

LED indicators provide clear visual feedback for power status and timing operation, enhancing user convenience and maintenance. Rated for a contact current of 5 A, with CO contact configuration and screw-type terminals to ensure secure wiring.

Operating temperature range from -10°C to 60°C and IP20 protection at terminals make it suitable for many industrial environments including manufacturing, HVAC systems, and process automation.

This timer relay includes 10 multifunctional timer modes accessible via an intuitive knob adjustment. LED status indicators simplify operational monitoring. Compact DIN rail mounting design for efficient space usage. Wide voltage range covers DC and AC supply options.

Reliable CO contact switch with 5 A current rating. Suitable for industrial, laboratory, automation, and manufacturing applications. Made in India and RoHS compliant. This RS PRO timer relay is an excellent choice for industrial automation and electrical control systems requiring precise time delay functions.
