Texas Instruments 4-Stage Through Hole Binary Counter 4000 Series 16 Pin PDIP CD4029BE

Free Delivery in India | Lowest Global Shipping Charges

Texas Instruments 4-Stage Through Hole Binary Counter 4000 Series 16 Pin PDIP CD4029BE

Name: Texas Instruments 4-Stage Through Hole Binary Counter 4000 Series 16 Pin PDIP CD4029BE
Brand: Texas Instruments
SKU: 187746
Price: 1.45 USD
Availability: InStock



Category Counter ICs Brand Texas Instruments Condition New

Specifications

Country of Origin	India
Brand	Texas Instruments
Height	4.57mm
Length	19.69mm
Model	CD4029BE
Mount Type	Through Hole
Series	CD4029B
Maximum Operating Temperature	125°C
Number Of Stages	4
Package Type	PDIP
Minimum Operating Temperature	-55°C
Standards/Approvals	RoHS
Pin Count	16
Number of Elements	1
Maximum Supply Voltage	18V
Logic Family	4000
Logic Function	Counter
Minimum Supply Voltage	3V
Direction Type	Bi-Directional
Reset Type	Asynchronous
Counter Type	Binary
Wide operating voltage range	3 to 18V
Counter IC Clock Frequency	2 MHz (5V), 4 MHz (10V), 5.5 MHz (15V)
Preset Type	Asynchronous

Key Features

Operates over a wide voltage range from 3V to 18V for flexible power applications.
Supports bi-directional counting with asynchronous preset and reset functionality.
High clock frequency performance up to 5.5 MHz at 15V supply voltage.
Through hole mount type ensures easy PCB assembly and replacement.
Compact 16-pin PDIP package measuring 19.69 mm by 4.57 mm.
Wide operating temperature range from -55°C to 125°C suitable for diverse environments.
Compliant with RoHS standards for environmental safety.
Part of the 4000 CMOS logic family known for reliability and low power consumption.

Product Description

Texas Instruments CD4029BE is a 4-stage 4000 series binary counter integrated circuit housed in a 16-pin PDIP through-hole package. This device offers robust counting functionality with both asynchronous preset and reset capabilities and operates bi-directionally, making it ideal for a wide range of digital electronics applications.

Engineered for versatility, it operates over a broad voltage range of 3V to 18V, supporting clock frequencies up to 2 MHz at 5V, 4 MHz at 10V, and up to 5.5 MHz at 15V supply voltages. The compact PDIP package dimensions are 19.69 mm in length and 4.57 mm in height, facilitating easy integration into electronic assemblies through through-hole mounting.

This IC is designed to endure harsh environments with an operating temperature range from -55°C to 125°C and complies with RoHS environmental standards. It belongs to the acclaimed Texas Instruments 4000 CMOS logic family, renowned for low power consumption and high reliability in industrial, laboratory, and manufacturing applications.

Wide operating voltage range enables flexible design choices. Supports asynchronous preset and reset for enhanced control. High clock frequency compatibility ensures rapid counting operations. Through-hole mounting simplifies assembly and maintenance.

Compact PDIP form factor suits space-constrained applications. Broad temperature rating supports industrial and automotive use. RoHS compliant, affirming environmental safety standards. Belongs to the Texas Instruments 4000 CMOS logic family known for durability.

This 4-stage binary counter IC is widely used in digital circuits requiring reliable, fast counting with flexible voltage and temperature tolerances. It is suitable for industrial machines, laboratory instruments, manufacturing automation, and electronic education projects.

Explore more Texas Instruments semiconductor solutions and related Counter ICs categories on EnvMart for comprehensive electronic components selection.
