Nexperia Zener Diode 1.3 V Single 250 mW 5% Surface Mount 3-Pin SOT-23 BZX84-C3V0215 BZX84-C3V0,215

Nexperia BZX84-C3V0215 Zener Diode is a high-reliability component designed for voltage regulation in electronic circuits. This single diode in a surface-mount 3-Pin SOT-23 package has a nominal Zener voltage of 1.3 V with a 5% tolerance and a power dissipation rating of 250 mW, supporting a test current of 5 mA. It is manufactured with automotive-grade quality standards (AEC-Q101), ensuring performance in harsh environmental conditions.

The device is suitable for industrial, automotive, and consumer electronics applications where stable voltage regulation is critical. Its compact dimensions (3 mm length, 1.1 mm height) support efficient PCB layout. The diode delivers low reverse leakage current (10 μA max) and low Zener impedance (95 Ω max), providing stable voltage under varying loads and temperatures.

Operating temperature range from -65°C to 150°C allows for deployment in extreme temperature environments. The diode's voltage temperature coefficient of -2.1 mV/°C facilitates predictable voltage shifts with temperature changes, beneficial for thermal management in devices.

This BZX84 series Zener diode is ideal for precision voltage regulation, overvoltage protection, and voltage reference circuits in semiconductor and electronics industries. The surface mount format supports modern automated assembly line processes, improving manufacturing efficiency and reliability.

The diode configuration is single element ensuring precise voltage regulation. It supports a test current of 5 mA enabling consistent zener voltage stabilization. Maximum reverse leakage current is limited to 10 μA for high efficiency.

It operates reliably between temperatures -65°C to 150°C with automotive AEC-Q101 qualification. Package dimensions are compact with 3 mm length and 1.1 mm height, easing PCB design constraints. The typical voltage temperature coefficient is -2.1 mV/°C for thermal stability.

It features low impedance of 95 Ω ensuring minimal voltage drop under operating load. Manufactured as part of the BZX84 series, widely used for voltage regulation in electronic circuits.

This product is made in China and corresponds to the BZX84 series of Zener Diodes by Nexperia. It is offered for applications in industrial machinery, automotive electronics, power supply regulation, and general semiconductor uses. Explore more semiconductor products on EnvMart for advanced electronic component sourcing.
