HARTING 20-Way IDC Connector Female for Cable, 2 Row 09185206803
Specifications
| Country of Origin | Romania |
|---|---|
| Voltage | 320V ac |
| Brand | HARTING |
| Orientation | Right Angle |
| Current | 2.5A |
| Mount Type | Cable |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Copper Alloy |
| Series | SEK 18 |
| Termination Type | IDC |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 20 |
| Contact Gender | Female |
| Connector Gender | Female |
| Shrouded/Unshrouded | Shrouded |
| HARTING 20-Way IDC Connector Female for Cable, 2 RowBrand | HARTING |
Key Features
- This IDC connector supports a current rating of 2.5 amps.
- It features a right-angle, female, shrouded cable mount design.
- Gold plated contacts ensure optimal conductivity and corrosion resistance.
- Operating temperature ranges from -55°C to 125°C for robust performance.
- Constructed with copper alloy contacts and polybutylene terephthalate housing.
- Termination type is insulation displacement connection (IDC) for quick assembly.
- The connector complies with various industry standards including DIN 41651 and UL certifications.
- Manufactured in Romania, guaranteeing quality and reliability.
Product Description
HARTING 09185206803 20-Way IDC Connector Female for Cable, 2 Row is engineered for secure and efficient electrical connections in industrial and electronic applications. This connector features 20 contacts arranged in 2 rows with a 2.54mm pitch, suitable for cable mounting with a shrouded, female, right-angle orientation.
Rated for a current of 2.5 amps and voltage of 320 volts AC, it supports reliable performance in demanding environments with an operating temperature range spanning from -55°C to 125°C. The contact plating is gold, enhancing conductivity and resistance against corrosion.
Constructed from copper alloy contacts and a durable polybutylene terephthalate housing, this connector ensures mechanical strength and long service life. It supports IDC (insulation displacement connection) termination for efficient and reliable cable assembly without the need for soldering.
The connector series SEK 18 adheres to stringent standards including UL E102079, CSA 98267, IEC 603-13, DIN EN 60603-13, MIL-C 83503, and others, ensuring compliance and quality assurance.
This IDC Connector supports a current rating of 2.5 amps. It features a right-angle, female, shrouded cable mount design. Gold plated contacts ensure optimal conductivity and corrosion resistance. Operating temperature ranges from -55°C to 125°C for robust performance.
Constructed with copper alloy contacts and polybutylene terephthalate housing. Voltage rating is 320 volts alternating current. Termination type is insulation displacement connection (IDC) for quick assembly. The connector complies with various industry standards including DIN 41651 and UL certifications.
Manufactured in Romania, guaranteeing quality and reliability.
This connector is suited for use in electronics manufacturing, power distribution, industrial control systems, and other commercial electrical applications. Its reliable performance and adherence to industry standards make it ideal for demanding professional environments.
Explore more high-quality connectors and electronic components on EnvMart to meet your precise industrial and electronic connectivity requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector supports a current rating of 2.5 amps.
It has a voltage rating of 320 volts AC.
The operating temperature range spans from -55°C to 125°C.
This model uses insulation displacement connection (IDC) termination for quick assembly.
It is constructed with copper alloy contacts and a polybutylene terephthalate housing.
The connector features 20 contacts arranged in 2 rows with a 2.54mm pitch.
This connector has a right-angle orientation.
This model is shrouded, enhancing connection safety.
It complies with various standards including DIN 41651 and UL certifications.
It is manufactured in Romania, ensuring quality and reliability.
It is suitable for electronics manufacturing, power distribution, and industrial control systems.
The pitch of the contacts is 2.54mm.
