Hirose DF11 Series Straight Surface PCB Header, 20 Contacts, 2 mm Pitch, 2 Row, Shrouded DF11

Hirose DF11 Series Straight Surface PCB Header, model DF11, is a high-quality connector designed for compact electronic applications requiring reliable board-to-board or wire-to-board connections. With a 2.00 mm pitch and 20 male contacts arranged in two rows, this shrouded header is engineered to save PCB space while maintaining superior performance.

The connector's polyamide housing combined with copper alloy contacts plated with tin ensures dependable electrical connectivity and mechanical strength. Its straight orientation and shrouded design provide enhanced protection to the contacts. A locking feature and guide ribs prevent incorrect insertion and twisting, securing mating connections effectively.

Rated at 250V and 2A current, the DF11 header supports a wide temperature range from -30°C to 85°C, making it suitable for various industrial, commercial, and consumer electronic environments. The metal fittings on surface mount versions improve PCB retention and prevent solder peeling, further enhancing durability.

This series is ideal for integration into portable and compact devices such as digital cameras, LCD panels, digital video recorders, automotive navigation systems, access control units, and instrumentation equipment where multiple signal connections and a minimal footprint are needed.

The header's compact 5 mm depth allows a double row of contacts to fit in the footprint typically occupied by single row connectors, optimizing board layout efficiency. It mates compatibly with Hirose DF11 series connector housings and PCB sockets designed for similar applications.

The connector features a shrouded, straight orientation optimizing signal integrity and mechanical stability. Double row design fits 20 contacts within a space-saving 5 mm depth configuration. Construction uses polyamide housing with copper alloy male contacts plated in tin for reliable conductivity.

Rated for 250V and 2A current, suitable for board-to-board and wire-to-board connector systems. Incorporates guide ribs and locking mechanism to prevent mismating and ensure secure connection. Operating temperature ranges from -30°C up to 85°C, enabling use in diverse environments.

Available in through-hole and surface mount versions with metal PCB fittings to enhance retention and solder joint durability. Ideal for compact electronic devices including digital cameras, LCD displays, car navigation, and measurement instruments.

Features robust four-wall shrouded design to protect contacts and improve connector longevity. Tin plated contacts meet industry standards for cost-effective performance without gold plating. Discover our full range of PCB Headers, connectors, and electronic components at EnvMart for industrial, manufacturing, and laboratory applications.
