Murata Wirewound Surface Mount Inductor 1608 Package Ferrite Core 0.033 μH ±5% 1.7 A DC Current LQW18CN33NJ00D
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Murata |
| Height | 0.8mm |
| Length | 1.6mm |
| Model | LQW18CN33NJ00D |
| Depth | 0.8mm |
| Packaging | Paper Tape |
| Series | LQW |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 0.033μH |
| Standards/Approvals | RoHS |
| Package/Case | 1608 |
| Maximum DC Current | 1.7A |
| Pin Count | 2 |
| Maximum DC Resistance | 35mΩ |
| Inductance Tolerance | ±5 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 1.8GHz |
| Inductor Construction | Wirewound |
Key Features
- Features a ferrite core for stable magnetic characteristics.
- Compact 1608 surface mount package with dimensions 1.6mm x 0.8mm x 0.8mm.
- Inductance value of 0.033 μH with a tolerance of ±5%.
- Maximum DC current rating of 1.7 A ensuring reliable performance under load.
- Low maximum DC resistance of 35 milliohms reducing power loss.
- Wirewound construction provides high Q value for effective signal filtering.
- RoHS compliant and uses solder termination style for ease of assembly.
- Operating temperature range from -40°C to 85°C suitable for industrial environments.
Product Description
Murata LQW18CN33NJ00D wirewound surface mount inductor features a compact 1608 package size with a ferrite core, providing an inductance of 0.033 μH with a ±5% tolerance. This high-quality inductor supports a maximum DC current of 1.7 A, making it suitable for demanding electronic circuit applications.
Designed with wirewound construction, the inductor offers high Q values, resulting in excellent attenuation characteristics within the passband of filters. Its low DC resistance of 35 milliohms minimizes power losses and improves overall circuit efficiency.
This surface mount component measures 1.6 mm in length, 0.8 mm in height, and 0.8 mm in depth, making it ideal for compact PCB layouts. The solder termination style allows reliable mounting on printed circuit boards, complying with RoHS environmental standards.
It operates reliably across a broad temperature range of -40°C to 85°C, suitable for industrial, telecommunications, and consumer electronics sectors. Furthermore, the component boasts a maximum self-resonant frequency of 1.8 GHz, enhancing its usability in RF choke and antenna matching applications where maintaining signal sensitivity is critical.
The inductor is supplied in paper tape packaging, facilitating efficient automated assembly processes. Originating from Japan, this Murata component exemplifies precise manufacturing and durability for surface mount designs.
Features a ferrite core for stable magnetic characteristics. Compact 1608 surface mount package with dimensions 1.6mm x 0.8mm x 0.8mm. Inductance value of 0.033 μH with a tolerance of ±5%. Maximum DC current rating of 1.7 A ensuring reliable performance under load.
Low maximum DC resistance of 35 milliohms reducing power loss. Wirewound construction provides high Q value for effective signal filtering. RoHS compliant and uses solder termination style for ease of assembly. Operating temperature range from -40°C to 85°C suitable for industrial environments.
Maximum self resonant frequency of 1.8 GHz ideal for RF applications. Explore additional electronic components and Surface Mount Inductors in the EnvMart catalog for further industrial and commercial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 0.033 μH with a tolerance of ±5%.
This inductor has a maximum DC current rating of 1.7 A, ensuring reliable performance under load.
The dimensions of the 1608 package are 1.6 mm in length, 0.8 mm in height, and 0.8 mm in depth.
The maximum DC resistance of this inductor is 35 milliohms, which helps reduce power loss.
It operates reliably across a temperature range from -40°C to 85°C, making it suitable for industrial environments.
The maximum self-resonant frequency of this model is 1.8 GHz, enhancing its usability in RF applications.
This inductor features a ferrite core, which provides stable magnetic characteristics.
The termination style of this surface mount inductor is solder, allowing for ease of assembly.
Yes, this inductor is RoHS compliant, adhering to environmental standards.
It is constructed using a wirewound design, which provides a high Q value for effective signal filtering.
This inductor is supplied in paper tape packaging, facilitating efficient automated assembly processes.
This model has a pin count of 2, suitable for surface mount applications.
