Murata Shielded Wirewound Surface Mount Inductor 10 μH ±20% 1 A Idc Ferrite Core 3225 Case LQH32PN100MNCL

Murata LQH32PN100MNCL shielded wirewound surface mount inductor is engineered for advanced electronic applications requiring reliable inductance of 10 μH with ±20% accuracy and a maximum DC current capacity of 1 A. The inductor utilizes a ferrite core, which provides superior magnetic performance and stability. Enclosed in a compact 3225 case size measuring 3.2 mm in length, 2.5 mm in depth, and 1.55 mm in height, this component is tailored for space-sensitive circuit designs.

The wirewound construction is coated with resin material enhancing mechanical strength and durability, making it suitable for industrial and consumer electronics. Its shielded design minimizes electromagnetic interference, ensuring signal integrity in densely packed electronic assemblies.

Operating temperature range from -40°C to 125°C enables this inductor to perform reliably in harsh environmental conditions such as automotive, telecommunications, and power supply applications. The maximum DC resistance is tightly controlled at 295 mΩ to optimize power efficiency.

Packaging is done on embossed tape reels, facilitating automated surface mount technology (SMT) assembly lines. The solder termination style ensures reliable electrical connection with printed circuit boards. The maximum self-resonant frequency of 30 MHz is ideal for high-frequency filtering and power supply boosting circuits.

This Murata LQH series inductor meets RoHS compliance standards reflecting its environmental safety and quality assurance. It is suited for various industrial use cases including digital cameras, mobile phones, TVs, and gaming machines.

Constructed with a ferrite core for enhanced magnetic properties. Compact 3225 package size measuring 3.2 mm in length and 1.55 mm in height. Maximum DC resistance of 295 mΩ ensures efficient current handling. Supports operating temperatures from -40°C up to 125°C suitable for diverse environments.

Embossed tape packaging facilitates automated assembly processes. RoHS compliant wirewound construction with solder termination style. Shielded design reduces electromagnetic interference for high performance. Maximum self resonant frequency of 30 MHz ideal for power supply booster circuits.
