HARTING DIN 41612 32 Way 2.54 mm Pitch Type Through Hole, Type C/2, Solder Class C2, 2 Row Female Straight 09032326845

HARTING 09032326845 DIN 41612 Connector is a 32-way, 2-row female backplane signal connector designed as per the DIN 41612 standard for PCB connection. It features a 2.54 mm pitch and a Type C/2 configuration with through-hole mounting, offering reliable and durable electronic interconnections in industrial and commercial electronics.

The connector's contacts are copper alloy plated with gold over nickel, providing low contact resistance up to 20mΩ and excellent mating cycle life. The housing is constructed from polybutylene terephthalate, a glass-fiber reinforced thermoplastic resin delivering robust mechanical integrity and resistance to thermal stress.

Engineered for operation in harsh environments, it supports temperatures from -55°C up to 125°C. This connector classifies as Class C2 with solder termination ensuring strong and durable mounting to circuit boards. It is widely used in applications including industrial automation, telecommunications, electronics instrumentation, and aerospace where reliable backplane connections are critical.

The connector complies with DIN 41612 series, supporting signal transmission and power up to 2A current per contact. Its straight female orientation and 2-row design facilitate integration into Eurocard racking and backplane systems, making it versatile for modular electronic assemblies.

This connector features 32 contacts arranged in two rows for high-density PCB connections. Gold over nickel plating enhances corrosion resistance and signal integrity. Durable polybutylene terephthalate housing material withstands mechanical and thermal stresses.

Operating temperature range from -55°C to 125°C suitable for diverse industrial environments. Copper alloy contacts provide reliable electrical performance with low resistance. Through-hole mounting provides stable mechanical attachment for circuit boards.

Class C2 solder termination ensures robust and lasting solder joints. Designed according to DIN 41612 standards ensuring compatibility with Eurocard racking systems.

This HARTING DIN 41612 connector series is ideal for industrial electronics, laboratory equipment, manufacturing instrumentation, telecommunications, and other technical applications requiring reliable and durable connector solutions. The German-manufactured connector reflects high-quality engineering and manufacturing standards.
