| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 0.47mm |
| Length | 1mm |
| Model | BZX8850S-C16YL |
| Mount Type | Surface |
| Series | BZX8850S |
| Maximum Operating Temperature | 150°C |
| Working voltage range | nominal 1.8 V to 75 V |
| Package Type | DFN1006BD-2 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 365mW |
| Diode Configuration | Single |
| Test Current It | 50μA |
| Maximum Reverse Leakage Current | 50nA |
| Nominal Zener Voltage Vz | 16V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 200Ω |
| Typical Voltage Temperature Coefficient | 10.4mV/K |
Nexperia BZX8850S-C16YL is a single Zener diode voltage regulator with a nominal voltage of 16 volts and a power dissipation rating of 365 milliwatts. It is designed as a low-current voltage regulator in a compact DFN1006BD-2 surface mount package featuring side-wettable flanks for PCB mounting.
This diode is suitable for industrial, automotive, and portable electronic applications requiring stable voltage regulation at low bias currents. Its ±5% voltage tolerance makes it reliable for precision voltage regulation tasks.
The device operates over a wide temperature range from -55°C up to 150°C, conforming to the AEC-Q101 automotive standard for enhanced robustness in demanding environments. Its low maximum reverse leakage current (50 nA) and low test current (50 µA) ensure minimal power loss and high efficiency.
The compact DFN package measures 1 mm length and 0.47 mm in height, facilitating space-saving PCB designs in electronic assemblies. Single Zener diode voltage regulator suitable for low current applications. Nominal Zener voltage of 16 V with ±5% tolerance ensures precision voltage regulation.
Maximum power dissipation of 365 mW supports reliable operation under load. Surface mount package DFN1006BD-2 with 2 pins for easy mounting. Operating temperature from -55°C to 150°C, complying with automotive quality standards.
Low test current and minimal reverse leakage current enhance energy efficiency. Typical voltage temperature coefficient of 10.4 mV/K enables stable voltage under temperature variations. Compact physical size (1 mm length, 0.47 mm height) supports miniaturized electronics.
This component is widely used in power management circuits, low current voltage regulation in consumer electronics, automotive electronics, and other industrial applications requiring precise voltage stabilization in a space-constrained environment.
