TDK 22 nF Multilayer Ceramic Capacitor 25V DC ±10% Tolerance Surface Mount 0402 Package C1005X7R1E223K050BB

TDK C1005X7R1E223K050BB is a high-quality multilayer ceramic capacitor designed for surface mount technology (SMT) applications. This capacitor offers a capacitance of 22 nF with a voltage rating of 25V DC and a tolerance of ±10%. Packaged in a 0402 case size, it measures approximately 1 mm in length and 0.5 mm in width and height, making it ideal for compact electronic devices and circuit boards requiring high reliability and precision.

Constructed using a stacked multilayer dielectric and electrode arrangement with X7R dielectric material, this capacitor delivers superior frequency characteristics including low equivalent series resistance (ESR) and inductance (ESL). It exhibits low self-heating values and excellent resistance to ripple currents, enhancing the stability and longevity of circuits across a wide operating temperature range from -55°C up to 125°C.

The solder termination enables secure mounting on printed circuit boards (PCBs) and supports automated manufacturing processes. Packed in tape & reel packaging, it is well-suited for high volume assembly lines.

This component is RoHS and REACH compliant, making it suitable for environmentally conscious industries such as telecommunications, consumer electronics, industrial robots, automotive electronics (non-automotive certified), and general purpose electronic equipment including AV systems, home appliances, and computers. Its monolithic structure provides high mechanical durability for demanding operational environments.

Compact 0402 package dimension with length 1 mm, width 0.5 mm, and height 0.5 mm. Capacitance: 22 nF with ±10% tolerance ensuring precision in electronic circuits. X7R dielectric construction delivering stable capacitance over wide temperature ranges.

Voltage rating of 25V DC suitable for general electronics and power supply applications. Low ESR and ESL characteristics optimize circuit performance and minimize losses. RoHS and REACH compliant for regulatory compliance in manufacturing.

Tape & reel packaging supports automated surface mount technology assembly.
