KEMET PFR510 Film Capacitor 2.2 nF ±5% 63 V DC 40 V AC Through Hole PFR510

Name: KEMET PFR510 Film Capacitor 2.2 nF ±5% 63 V DC 40 V AC Through Hole PFR510
Brand: KEMET
SKU: 177322
Price: 0.69 USD
Availability: InStock



Category Film Capacitor Brand KEMET Condition New

Specifications

Country of Origin	Indonesia
Brand	KEMET
Height	6mm
Length	7.2mm
Model	PFR510
Packaging	Bag
Width	4.5mm
Mount Type	Through Hole
Series	PFR510
Maximum Operating Temperature	100°C
Tolerance	±5 %
Insulation resistance	100000 MΩ
Capacitance	2.2nF
Minimum Operating Temperature	-55°C
Terminal type	Radial
Lead Length	4mm
Standards/Approvals	IEC 60068-1, UL, RoHS
Pin Count	2
Rated AC Voltage	40V ac
Rated DC Voltage	63V dc
Lead Pitch	5mm
Lead Diameter	0.5mm

Key Features

Compact radial leaded capacitor with 5mm lead pitch for easy through hole PCB mounting.
High insulation resistance of 100000 MΩ ensures low leakage current during operation.
Suitable for high-speed and high-frequency applications needing low losses and high stability.
Operates reliably in temperature range from -55°C to 100°C with flame retardant plastic case.
Encapsulated with flame retardant plastic and sealed with epoxy resin meeting UL 94V-0 standards.
Meets international standards IEC 60068-1, UL and RoHS compliance.
Rated for 40 V AC and 63 V DC voltage with radial terminal type and 4mm lead length.
Pin count of 2 with lead diameter of 0.5mm ensures secure soldering and electrical connection.

Product Description

KEMET PFR510 Film Capacitor 2.2 nF model PFR510 is a high-performance film capacitor designed for through hole mounting with a radial lead configuration. It features a capacitance of 2.2 nanofarads with a tolerance of ±5% and is rated for a maximum DC voltage of 63 V and AC voltage of 40 V, suitable for demanding electronic applications.

The capacitor is constructed with a flame retardant plastic case sealed using epoxy resin to UL 94V-0 standards, providing safety and reliability in operation at temperatures ranging from -55°C to 100°C. Its radial lead design, with a 5mm lead pitch and 0.5mm lead diameter, facilitates easy mounting on printed circuit boards.

This model meets IEC 60068-1, UL certification standards, and RoHS compliance, ensuring environmental safety and adherence to international quality norms. Its high insulation resistance of 100000 MΩ guarantees minimal leakage and excellent stability over time.

The PFR510 series is suitable for high-speed, high-frequency applications requiring low losses and high stability, including snubber circuits and pulse applications commonly found in industrial electronics and power supply systems.

Capacitance: 2.2 nF with ±5% tolerance ensures precision performance. Voltage ratings: 63 V DC and 40 V AC provide broad usage scenarios. Through hole mounting with radial leads and 5 mm pitch supports robust mechanical and electrical connection.

Wide operating temperature range from -55°C to 100°C for versatile environments. Flame retardant encapsulation and epoxy seal enhance safety and durability. Compliance with IEC 60068-1, UL, and RoHS standards ensures quality and environmental friendliness.

Insulation resistance of 100000 MΩ for superior electrical isolation. Manufactured in Indonesia under strict quality controls.

This capacitor is ideal for industrial electronic assemblies, manufacturing equipment, power electronics, and other applications where reliability and performance are critical. Explore more Film Capacitors and similar electronic components offered by KEMET on EnvMart.
