STMicroelectronics Operational Amplifier 22 MHz Gain Bandwidth Product 5-Pin SOT-23 36V TSB7191IYLT
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.45mm |
| Length | 3mm |
| Model | TSB7191IYLT |
| Width | 1.75mm |
| Mount Type | Surface |
| Low Noise | 12 nV/√Hz |
| Series | TSB7191 |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Standards/Approvals | JEDEC, ANSI/ESD STM5.3.1 |
| Pin Count | 5 |
| Automotive Standard | AEC-Q3, AEC-Q100 |
| Maximum Supply Voltage | 36V |
| Minimum Supply Voltage | 2.7V |
| GBP - Gain Bandwidth Product | 22MHz |
| Input Bias Current | 0 nA |
| Slew Rate | 12V/μs |
| Input Offset Current | 10 nA |
| Extended temperature range | -40 °C to +125 °C |
Key Features
- High gain bandwidth product of 22 MHz ensuring fast response.
- Single channel operational amplifier in compact SOT-23 surface mount package.
- Wide supply voltage range from 2.7 V to 36 V supporting single and dual supply operation.
- Operating temperature range from -40 °C to +125 °C for extended reliability.
- Low input offset voltage maximum 300 μV at 25 °C for precision performance.
- Rail-to-rail input and output capability enhancing signal handling range.
- Low input bias current of 0 nA minimizing error in sensitive circuits.
- Fast slew rate of 12 V/μs for dynamic applications.
Product Description
The STMicroelectronics TSB7191IYLT operational amplifier is a high-performance BiCMOS device designed for precision applications requiring wide bandwidth and low noise. It features a 22 MHz gain bandwidth product and is housed in a compact 5-pin SOT-23 surface mount package, making it ideal for space-constrained designs.
This amplifier supports a wide supply voltage range from 2.7 V to 36 V, accommodating single supply operation as well as dual supplies from ±1.35 V to ±18 V. The device guarantees rail-to-rail input and output, facilitating maximum signal swing and improved system performance. Its low maximum input offset voltage of 300 μV at 25 °C ensures accurate signal amplification with minimal error.
Designed to operate reliably over an extended temperature range from -40 °C to +125 °C, the TSB7191IYLT meets stringent automotive standards including AEC-Q3 and AEC-Q100, making it suitable for automotive, industrial, and consumer electronics applications.
Other notable features include a fast slew rate of 12 V/μs, very low input bias current of 0 nA, integrated EMI filter for noise reduction, and a low noise spectral density of 12 nV/√Hz. These characteristics make it widely applicable for motor control, actuator driving, filters, hall effect sensors, and resistive transducer circuits.
High bandwidth and precision amplification with 22 MHz gain bandwidth product. Compact 5-pin SOT-23 package for surface mounting and space efficiency. Wide supply voltage range from 2.7 V to 36 V for flexible power options.
Extended operating temperature range from -40 to 125 °C for harsh environments. Rail-to-rail input/output allows maximum output swing and versatility. Low offset voltage and bias current ensure high accuracy in signal processing.
Automotive-grade reliability with AEC-Q3 and AEC-Q100 certifications. Integrated EMI filter and low noise enhance signal integrity. Suitable for a variety of uses in industrial, automotive, and electronics systems.
STMicroelectronics offers this operational amplifier as a reliable component for designers seeking high performance and robustness in analog signal processing applications. Explore more Operational Amplifiers and related electronic components on EnvMart for your engineering projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 22 MHz, ensuring fast response in various applications.
It supports a wide supply voltage range from 2.7 V to 36 V, accommodating both single and dual supply operations.
This operational amplifier operates reliably over an extended temperature range from -40 °C to +125 °C.
The maximum input offset voltage is 300 μV at 25 °C, ensuring accurate signal amplification with minimal error.
It has a fast slew rate of 12 V/μs, making it suitable for dynamic applications.
The TSB7191IYLT is housed in a compact 5-pin SOT-23 surface mount package.
It features a very low input bias current of 0 nA, which minimizes error in sensitive circuits.
It meets stringent automotive standards including AEC-Q3 and AEC-Q100, making it suitable for automotive applications.
The low noise spectral density of this operational amplifier is 12 nV/√Hz, enhancing signal integrity.
The dimensions of this operational amplifier are 3 mm in length, 1.75 mm in width, and 1.45 mm in height.
This operational amplifier is widely applicable for motor control, actuator driving, filters, hall effect sensors, and resistive transducer circuits.
It complies with JEDEC and ANSI/ESD STM5.3.1 standards, ensuring reliability in electronic applications.
