TE Connectivity Automotive Relay 24V DC Coil Voltage 4.1W Power 20A Switching Current SPST 1-1393315-1

TE Connectivity model 1-1393315-1 is an Automotive Relay engineered for high-performance electrical switching within automotive and industrial applications. It features a 24V DC coil voltage and a coil power rating of 4.1 watts, optimized for durable and efficient operation under demanding conditions. The relay comes with a Single Pole Single Throw (SPST) contact configuration and silver alloy contact material, ensuring minimal contact resistance and reliable switching.

This relay is designed for a wide temperature operating range from -40°C up to 125°C, making it suitable for varied environmental conditions encountered in automotive and industrial settings. The compact size of 63mm length, 40mm height, and 45mm depth allows flexible installation within confined spaces.

Quick connect terminal types facilitate straightforward wiring and integration into switching circuits. It offers outstanding electrical ratings with a limiting continuous current of 130A at 85°C and the ability to switch currents up to 300A. The sealed and dustproof housing protects the internal components from moisture, dust, and vibration, ensuring long operational life in harsh automotive environments.

Typical applications include engine control units, glow plug activation, heated front screens, preheating systems for diesel engines and catalytic converters, as well as switches for loading ramps and start/stop functionalities.

The relay is manufactured in Portugal under stringent quality controls, which guarantee consistent performance and reliability for automotive electrical systems. Operates reliably between -40°C to 125°C temperature range.

Equipped with silver alloy contacts for efficient conductivity. Compact dimensions measuring 63mm length, 40mm height, and 45mm depth. Features quick connect terminals for easy installation. Sealed and dustproof design ensures durability in harsh environments.

Withstands heat, moisture, and vibration for automotive applications. Capable of continuous current up to 130A at 85°C and switching current capability up to 300A. Suitable for engine control, glow plug systems, heated front screens, and preheating systems.
