Infineon LED Driver IC VDSON-8 20V 3A 8-Pin 2EDL8123GXUMA1

Free Delivery in India | Lowest Global Shipping Charges

Infineon LED Driver IC VDSON-8 20V 3A 8-Pin 2EDL8123GXUMA1

Name: Infineon LED Driver IC VDSON-8 20V 3A 8-Pin 2EDL8123GXUMA1
Brand: Infineon
SKU: 174575
Price: 1.89 USD
Availability: InStock



Category LED Driver IC Brand Infineon Condition New

Specifications

Country of Origin	India
Brand	Infineon
Height	1mm
Length	4mm
Model	2EDL8123GXUMA1
Width	4mm
Mount Type	Through Hole
Series	2EDL8123G
Output Current	3A
Maximum Operating Temperature	150°C
Package Type	VDSON-8
Minimum Operating Temperature	-40°C
Input Voltage	20V
Number of Pins	8

Key Features

Operates at an input voltage of 20 volts DC.
Supports output current up to 3 amperes for effective LED driving.
Compact VDSON-8 package with 8 pins for through-hole mounting.
Wide operating temperature range from -40°C up to 150°C.
Designed with built-in hysteresis for enhanced noise immunity.
Features shoot-through protection for system robustness.
Fast propagation delay suitable for telecom and datacom applications.

Product Description

Infineon 2EDL8123GXUMA1 is a high-side low-side LED Driver IC housed in a VDSON-8 through-hole package measuring 4 mm by 4 mm by 1 mm. It is engineered to operate at a 20V DC input voltage and deliver up to 3A output current, making it suitable for advanced switching converters in telecom and datacom applications. Its design incorporates differential inputs with built-in hysteresis to enhance noise immunity, delivering reliable performance in demanding environments.

The driver offers inherent shoot-through protection which aids in system robustness and reliability. Its fast propagation delay supports efficient switching operations, optimizing overall system efficiency.

Operating temperature spans from -40°C to a maximum of 150°C, enabling deployment in various industrial and commercial LED lighting applications. The device does not adhere to any specific automotive standards or certifications, focusing on general industrial usage.

The compact VDSON-8 package with 8 pins allows ease of integration in designs requiring through-hole mounting. Suitable sectors include industrial electronics, LED lighting components manufacturing, telecom infrastructure, and other power electronics systems.

Operates at an input voltage of 20 volts DC. Output current capability of up to 3 amperes. Package type: VDSON-8 with 8 pins. Temperature range: -40°C to 150°C. Built-in hysteresis for improved noise immunity. Shoot-through protection for operational robustness.

Fast propagation delay for high switching efficiency. Compact physical dimensions of 4 mm length, 4 mm width, 1 mm height.

This Infineon LED Driver IC is ideal for use in industrial electronics, telecommunications, data communication equipment, power converters, and LED lighting modules, offering precision control and protection for LED drivers in various settings.
