Infineon LED Driver IC, 20V Input Voltage, 4A Output Current, 8-Pin VDSON-8 Package 2EDL8124GXUMA1

Infineon 2EDL8124GXUMA1 is a high-side low-side LED driver IC engineered specifically for advanced switching converter applications such as telecom and datacom systems. It operates at a 20V DC input voltage and can supply an output current of up to 4A through an 8-pin VDSON-8 package, making it ideal for compact and efficient circuit designs.

This device features through hole mounting for ease of installation on printed circuit boards. With operating temperatures ranging from -40°C to 150°C, it delivers robust performance across diverse environmental conditions.

The IC incorporates built-in hysteresis for enhanced noise immunity, protecting the system from voltage fluctuations and transient disturbances. Additionally, its inherent shoot-through protection contributes to system reliability by preventing simultaneous conduction of switches which could cause damage.

Dimensionally, the device measures 4mm in length, 4mm in width, and 1mm in height, suitable for space-constrained electronic assemblies. Industrial and commercial applications include telecom infrastructure, datacom modules, power management units, and advanced LED lighting drivers.

This LED driver IC utilizes an 8-pin VDSON-8 package for compactness. Input voltage rating is 20 volts DC for stable operation. Maximum output current capability is 4 amperes ensuring high load handling. Supports through hole mount type for easy PCB integration.

Operates reliably within -40°C to 150°C temperature range. Includes built-in hysteresis and shoot-through protection for robust noise immunity. Compact dimensions measuring 4mm length, 4mm width, and 1mm height contribute to efficient space usage.

Designed for fast propagation delay to improve switching performance. Browse EnvMart's Electronics Components category for more high-quality LED Driver ICs and semiconductor solutions.
