Toshiba Photocoupler Surface Mount 4-Pin SO Package MOSFET Output 1.4V Forward Voltage TLP172AM(TPR,E(O
Specifications
| Country of Origin | India |
|---|---|
| Brand | Toshiba |
| Model | TLP172AM(TPR,E(O |
| Packaging | SMD |
| Mount Type | Surface |
| Output type | MOSFET |
| Series | TLP |
| Maximum Operating Temperature | 110°C |
| Package Type | SO |
| Minimum Operating Temperature | -40°C |
| Maximum input current | 30mA |
| Number Of Channels | 1 |
| Standards/Approvals | UL1577, EN60747-5-5 (VDE), UL508, RoHS, CSA Component Acceptance Service No.5A |
| Maximum Forward Voltage | 1.4V |
| Number of Pins | 4 |
| Typical Rise Time | 0.6ms |
| Typical Fall Time | 0.1ms |
Key Features
- Optically couples gallium arsenide infrared LED to a photo MOSFET.
- Surface mount design for compact PCB footprint.
- Maximum forward voltage of 1.4V for input LED.
- Supports a maximum input current of 30mA.
- Typical rise time is 0.6ms with fall time of 0.1ms.
- Operates reliably across a temperature range from -40°C to 110°C.
- Isolation voltage rating of 3750Vrms ensures signal integrity.
- Complies with UL1577, EN60747-5-5 (VDE), UL508, RoHS, and CSA standards.
Product Description
Toshiba TLP172AM(TPR,E(O photocoupler is a high-performance optoelectronic component designed for industrial applications requiring reliable isolation between input and output signals. Featuring a gallium arsenide infrared emitting diode optically coupled with a photo MOSFET in a compact 4-pin SO package, this device offers efficient switching capabilities with a MOSFET output type.
The device is surface mountable (SMD) allowing for seamless integration into printed circuit boards and space-saving layouts. It supports a maximum forward voltage of 1.4V on the input LED and a maximum input current of 30mA, providing robust input signal handling.
This photocoupler operates effectively over a broad temperature range from -40°C to 110°C, making it suitable for harsh industrial environments. With a typical rise time of 0.6ms and fall time of 0.1ms, it enables fast response suitable for timing-sensitive applications.
The device meets stringent standards including UL1577, EN60747-5-5 (VDE), UL508, RoHS compliance, and CSA Component Acceptance Service, underscoring quality and safety for industrial usage. Its isolation voltage rating of 3750Vrms ensures high electrical isolation integrity between input and output circuits.
Typical applications include security system control, factory automation systems, and as replacements for mechanical relays where silent and high-speed switching is advantageous. The photocoupler is halogen free and normally opened, aligning with modern environmental and operational requirements.
Optical isolation between input and output to prevent noise and interference. Surface mount 4-pin SO package for compact and efficient PCB design. Industry-standard electrical characteristics with assured quality certifications.
Broad operating temperature range for varied industrial environments. Fast switching speed with low input forward voltage for energy efficiency. Halogen free construction supporting environmental sustainability. Wide range of industrial applications including security and automation.
Reliable MOSFET output providing mechanical relay replacement. Compliance with key international safety and quality standards. Long lifespan and stable performance under continuous operation. Explore more electronic components and Optocoupler devices at EnvMart for industrial, laboratory, and commercial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum input current for the TLP172AM(TPR,E(O is 30mA.
The typical rise time is 0.6ms and the fall time is 0.1ms.
It operates effectively over a temperature range from -40°C to 110°C.
This model features a MOSFET output type.
The maximum forward voltage for the input LED is 1.4V.
It complies with UL1577, EN60747-5-5 (VDE), UL508, RoHS, and CSA Component Acceptance Service standards.
The TLP172AM(TPR,E(O comes in a surface mount 4-pin SO package.
This model has 1 channel.
The isolation voltage rating is 3750Vrms, ensuring high electrical isolation integrity.
Yes, it operates reliably across a broad temperature range, making it suitable for harsh industrial environments.
The dimensions are defined by its 4-pin SO package, but specific measurements are not provided in the data.
Typical applications include security system control and factory automation systems, as well as replacements for mechanical relays.
